MULTILIN FMOD136-23 feeder protection relay

MULTILIN FMOD136-23 feeder protection relay

Product Details Introduction

GE Multilin FMOD136-23 is a relay specifically designed for feeder protection. It is mainly used in power systems to protect feeders and ensure the reliability and stability of power supply. The following is the detailed information of the relay:

Product Overview

Model: FMOD136-23

Product Type: Feedline Protection Relay

main features

Protection function: Provides comprehensive feeder protection functions, including overcurrent protection, ground fault protection, undervoltage/overvoltage protection, etc.

Advanced Control: Supports functions such as automatic restart, logical control, and delayed operation, enhancing the system's control capabilities.

Real time monitoring: capable of monitoring the status and operating parameters of feeders in real time, such as current, voltage, etc.

User Interface: Equipped with a user-friendly graphical interface for easy configuration, operation, and monitoring.

Communication capability: Supports multiple communication protocols (such as Modbus DNP3、IEC 61850）， Facilitate integration with other devices and systems.

technical specifications

Model: FMOD136-23

Protection function:

Overcurrent protection: detects and responds to situations where the current exceeds the set value.

Ground fault protection: Monitor ground faults and provide protective measures.

Undervoltage/Overvoltage Protection: prevents abnormal voltage from causing damage to equipment.

Control functions: including automatic restart, delayed operation, logic control, etc.

Data collection: Real time collection and analysis of parameters such as current and voltage.

Display and Interface: High resolution display screen and user-friendly interface.

Communication interface: Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850.

Environmental adaptability: Suitable for a wide range of working temperatures and humidity conditions, suitable for various industrial environments.

Installation method: Supports panel installation or DIN rail installation.

application area

Power system protection: used for feeder protection in power systems to ensure the safety and stability of power supply.

Industrial automation: integrated into industrial automation systems to protect feeder equipment.

Building power management: used for feeder protection and management inside buildings to prevent equipment damage.

Energy management: Help optimize energy use, provide detailed monitoring and protection functions.

Installation and maintenance

Installation: The equipment is usually installed through a panel or DIN rail. Please refer to the product manual for specific installation methods.

Maintenance: The design is simple and easy to maintain and inspect on a daily basis. It is recommended to regularly check the equipment status and connection wires to ensure normal operation.

advantage

Comprehensive protection: integrates multiple protection functions to ensure the safe operation of the feeder.

Flexible control: Provides multiple control options to adapt to different application needs.

Powerful communication capability: Supports multiple communication protocols, making it easy to integrate with other devices and systems.

User friendly: The intuitive interface and operational functions simplify the configuration and monitoring process.

summary

The GE Multilin FMOD136-23 feeder protection relay is a high-performance protection device designed specifically for feeder protection in power systems. Its comprehensive protection functions, advanced control capabilities, and powerful communication capabilities make it an ideal choice for power and industrial applications.

Product image
