MULTILIN G60E00HF8LH6 Generator Protection System

MULTILIN G60E00HF8LH6 Generator Protection System

Product Details Introduction

GE Multilin G60E00HF8LH6 is a generator protection system designed for comprehensive protection of generator sets, providing efficient fault detection and system protection. This system integrates multiple protection functions and supports flexible configuration options, suitable for various generator application scenarios.

Product Overview

Model: G60E00HF8LH6

Product Type: Generator Protection System

main features

Comprehensive protection function: It integrates multiple protection functions, including but not limited to overcurrent, overload, ground fault, undervoltage/overvoltage, overspeed, step loss, etc.

Real time monitoring: capable of monitoring the status of the generator in real time, providing real-time data and alarm functions.

Advanced Control: Supports advanced functions such as automatic restart, logical control, and delayed operation to meet complex operational requirements.

User Interface: Equipped with an intuitive graphical user interface (GUI), it simplifies the system's operation and configuration process.

Communication capability: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, making it easy to integrate with other devices and systems.

technical specifications

Model: G60E00HF8LH6

Protection function:

Overcurrent protection: detects and responds to situations where the generator current exceeds the set value.

Overload protection: prevents the generator from being damaged due to overload.

Ground fault protection: Monitor generator ground faults and provide protective measures.

Undervoltage/Overvoltage Protection: prevents abnormal voltage from causing damage to the generator.

Overspeed protection: Monitor the generator speed to prevent damage caused by overspeed.

Out of step protection: Check whether the generator is out of step to ensure the normal operation of the system.

Control functions: including automatic restart, delayed operation, logic control, etc.

Data collection: Real time collection and analysis of parameters such as current, voltage, power factor, temperature, etc.

Display and Interface: Equipped with a high-resolution display screen and user-friendly interface.

Communication interface: Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850, etc.

Environmental adaptability: Suitable for a wide range of working temperatures and humidity conditions, suitable for various industrial environments.

Installation method: Usually supports panel installation or DIN rail installation. Please refer to the product manual for specific installation methods.

application area

Generator protection: Used for comprehensive protection of the generator set, ensuring the safe and reliable operation of the generator.

Industrial automation: Integrated into industrial automation systems, providing protection and control functions for generators.

Building power management: used for the protection and management of generators inside buildings, ensuring the safe operation of equipment.

Energy management: Real time monitoring and optimization management of generators in the energy management system.

Installation and maintenance

Installation: The device is usually installed through a panel or DIN rail. Please refer to the product manual for specific installation steps.

Maintenance: The design is simple and easy to maintain and inspect on a daily basis. It is recommended to regularly check the equipment status and connection wires to ensure normal operation.

advantage

Comprehensive protection: integrates multiple protection functions to ensure the safe and stable operation of the generator set.

Flexible control: Provides multiple control options to adapt to different application needs.

Powerful communication capability: Supports multiple communication protocols, making it easy to integrate with other devices and systems.

User friendly: The intuitive interface and operational functions simplify the configuration and monitoring process.

summary

The GE Multilin G60E00HF8LH6 generator protection system is a comprehensive protection device designed specifically for generator sets, providing efficient protection and monitoring functions. Its comprehensive protection functions, flexible control options, and powerful communication capabilities make it an ideal choice in power systems.

Product image
