MULTILIN UR 6NH Digital Input/Output Module

MULTILIN UR 6NH Digital Input/Output Module

Product Details Introduction

The Multilin UR 6NH is a digital input/output module designed specifically for power protection and control systems, commonly used in the GE Multilin Universal Relay (UR) series. This module provides flexible input/output options suitable for various application scenarios, including protection and control of power generation, transmission, and distribution systems.

Product Overview

Model: UR 6NH

Brand: Multilin

Product Type: Digital Input/Output Module

Application area: Protection and control of power systems

major function

Digital input:

Provide multiple digital input channels for monitoring switch status, device status, and other binary signals.

Support de jitter filtering to reduce signal noise and false triggering.

Programmable input logic to adapt to different application requirements.

Digital output:

Provide multiple digital output channels for controlling relays, circuit breakers, and other actuators.

The output channel supports timed control and logical control, adapting to complex protection and control strategies.

Provide fault alarm function and timely feedback on system status.

technical specifications

Input channels: Usually provide 8 to 16 digital input channels, the specific number varies depending on the model.

Output channels: Usually provide 8 to 16 digital output channels, the specific number varies depending on the model.

Input voltage range: Supports multiple input voltage levels, commonly including 24VDC, 48VDC, and 110VDC.

Output voltage range: Supports multiple output voltage levels, commonly including 24VDC, 48VDC, and 110VDC.

Communication interface: Supports common industrial communication protocols such as Modbus, DNP3, IEC 61850, etc., making it easy to integrate with other systems.

Environmental adaptability: Designed for industrial environments, capable of stable operation under a wide temperature range and high humidity conditions.

Installation method: Supports DIN rail and panel installation for easy installation and maintenance.

application area

Power plant protection and control: Monitor and control the status of generators, transformers, and other critical equipment to ensure safe system operation.

Transmission system protection and control: Provide line protection and fault isolation functions in transmission lines.

Protection and control of distribution system: Monitor and control switches and circuit breakers in the distribution network to ensure power supply reliability.

Industrial automation system: In industrial automation systems, equipment monitoring and control functions are provided to ensure the safety and stability of the production process.

Installation and maintenance

Installation:

Location: Installed inside the distribution cabinet or control cabinet, connected to protective equipment and systems.

Method: Supports DIN rail and panel installation, ensuring easy and secure installation.

maintain:

Regular inspection: Regularly check the connection and operation status of the module to ensure its normal operation.

Firmware update: Perform firmware updates as needed to enhance functionality and performance.

Fault diagnosis: Utilize the diagnostic function of the module to promptly identify and solve potential problems.

advantage

High reliability: Provide highly reliable digital input/output functions to ensure the safe operation of the power system.

Flexibility: Supports multiple input/output options and communication protocols to meet different application requirements.

Data recording: Provide detailed input/output data and event records for easy analysis and maintenance.

High integration: seamlessly integrated with other modules in the GE Multilin UR series, forming a complete protection and control solution.

summary

The Multilin UR 6NH digital input/output module is a high-performance power system protection and control device that provides flexible input/output options and high reliability performance. Its comprehensive functionality and flexible application options make it an ideal choice in the field of power system protection and control.

Product image
