Multilin F60C00HCHFAH6 Relay Panel

Multilin F60C00HCHFAH6 Relay Panel

Product Details Introduction

The Multilin F60C00HCHFAH6 relay panel is part of the GE Multilin series, designed specifically for distribution and substation applications, providing comprehensive feeder protection and control functions. This relay panel has multiple protection, monitoring, and control functions, suitable for various power system environments.

Main functions and features

feeder protection

Overcurrent protection: Provides instantaneous, timed, and inverse time overcurrent protection to ensure rapid response and isolation of faults in the event of a malfunction.

Grounding protection: equipped with grounding fault protection function, monitoring and protecting grounding faults, preventing equipment damage and power outage accidents.

Voltage protection

Overvoltage and undervoltage protection: protects the system from abnormal voltage effects and ensures stable operation of equipment and systems.

Zero sequence voltage protection: used to detect and protect ground faults, providing additional protection layer.

Frequency protection

High and low frequency protection: Monitor the system frequency to prevent system instability and equipment damage caused by abnormal frequency.

Circuit breaker control

Automatic reclosing function: After the fault is cleared, the automatic reclosing function can improve the power supply reliability of the system.

Circuit breaker failure protection: detect circuit breaker failure and quickly take measures to isolate the faulty area.

Communication and Interface

Multiple communication protocols: Supports communication protocols such as Modbus, DNP3, IEC 61850, etc., ensuring compatibility with other systems.

Standard interface: Provides Ethernet, RS-232, and RS-485 interfaces for easy data exchange with external devices and systems.

Data recording and event analysis

Fault record: Record detailed information of fault events for post analysis and troubleshooting.

Event logs and waveform capture: Capture the electrical waveform at the time of an event to assist users in conducting in-depth event analysis and diagnosis.

User interface and configuration

Intuitive LCD display: Equipped with an intuitive display screen, users can easily view and set parameters.

Graphical configuration tool: Through graphical configuration tools, users can simplify the configuration process and improve work efficiency.

Remote configuration and monitoring: Supports remote configuration and monitoring functions, facilitating centralized management and maintenance.

High reliability and environmental adaptability

Industrial grade design: With high reliability design, it can adapt to various harsh working environments.

Wide temperature range operation: capable of stable operation over a wide temperature range, ensuring the reliability of the system.

application area

transformer substation

Main transformer protection: provides comprehensive protection for the main transformers in the substation to prevent faults from affecting system stability.

Busbar protection: Monitor and protect the busbars in substations to prevent the expansion of faults and ensure the stability of the power system.

Power transmission and distribution system

Line protection: provides efficient protection for transmission lines to prevent widespread power outages caused by faults.

Segmented protection: Protecting and controlling each segment in the distribution system to improve the reliability of the distribution network.

Industrial power system

Equipment protection: Protecting critical equipment in industrial power systems to prevent production interruptions caused by malfunctions.

Grid stability: By providing comprehensive protection functions, ensure the stable operation of industrial power systems.

summary

The Multilin F60C00HCHFAH6 relay panel provides advanced feeder protection, voltage protection, frequency protection, and circuit breaker control functions, suitable for key equipment protection in substations, transmission and distribution systems, and industrial power systems. Its high sensitivity, high reliability, and rich communication interfaces make it an important component of power protection and control systems.
