Product Details Introduction

MULTILIN T60G03ACHF8HH6 management relay is an advanced relay in the GE Multilin series, used for protection and control applications in power systems. It provides comprehensive management functions, including protection, monitoring, control, and communication capabilities. The following is detailed information about the management relay:

Main functions and features

Protection function

Overcurrent protection: including instantaneous, timed, and inverse time overcurrent protection, used to deal with short circuits and overloads.

Ground fault protection: Detecting ground faults can isolate the faulty part in a timely manner and prevent system damage.

Undervoltage and Overvoltage Protection: Provides voltage protection to prevent damage to the system caused by abnormal voltage.

Load imbalance protection: detects and protects system issues caused by load imbalance.

control function

Automatic reclosing: automatically restores power supply after the fault is cleared, improving the reliability of the system.

Circuit breaker control: It can automatically or manually control the switch operation of the circuit breaker, supporting fault isolation and system maintenance.

Monitoring and Diagnosis

Real time data monitoring: Monitor real-time data such as current, voltage, power, etc., and provide a detailed view of the system status.

Event recording: Record fault events and system operation information to assist in troubleshooting and system analysis.

Waveform capture: Capture electrical waveform data for in-depth analysis for diagnosis and optimization.

communication interface

Multi protocol support: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, etc., ensuring compatibility with other devices and systems.

Communication interface: equipped with Ethernet, RS-232, RS-485 and other interfaces, supporting communication and data exchange with external systems.

user interface

Display screen: usually equipped with an LCD display screen, providing an intuitive user interface for displaying system status and making settings.

Configuration tool: Simplify system settings and management through graphical configuration tools, supporting users to perform detailed configurations.

High reliability and environmental adaptability

Industrial grade design: Meets industrial grade standards and can operate stably under harsh environmental conditions.

Wide temperature range: Suitable for different environmental conditions to ensure long-term stable operation.

application area

transformer substation

System protection: Provide equipment protection in substations to prevent equipment damage and system failures.

Automatic control: Realize the automation control of substations, improve operational efficiency and reliability.

Distribution system

Feedline management: used for feeder protection and control in distribution systems, optimizing system performance.

Fault isolation: Provide effective fault isolation function to reduce the range of system power outages.

Industrial power system

Key equipment protection: provides protection for key equipment in industrial power systems to prevent production interruptions caused by faults.

Power monitoring: Real time monitoring of the operational status of industrial power systems to assist in system maintenance and optimization.

summary

MULTILIN T60G03ACHF8HH6 management relay is a powerful power system protection and management component with comprehensive protection, control, monitoring, and communication capabilities. Its high-performance design and flexible configuration options make it widely applicable in substations, distribution systems, and industrial power systems.
