Multilin L90N02HKHF8LH6 Relay Panel

Multilin L90N02HKHF8LH6 Relay Panel

Product Details Introduction

The Multilin L90N02HKHF8LH6 relay panel is a component in the GE Multilin series, commonly used for relay control and protection in power systems. It has high-performance design in terms of relay panel configuration and functionality, providing multiple protection and control options. The following is the detailed information of the relay panel:

Main features and functions

Panel design

Sturdy structure: Panels are typically made of durable metal materials to ensure long-term stable operation.

Modular configuration: supports the installation and configuration of multiple relay modules, making it convenient for users to customize according to their needs.

Protection design: It has industrial grade protection design such as dust-proof and waterproof to protect internal relays and circuit boards from environmental influences.

Protection function

Comprehensive protection: supports multiple protection functions, including overcurrent protection, overvoltage protection, undervoltage protection, ground fault protection, etc.

Programmable function: Provides flexible programming options, allowing users to customize protection logic and parameter settings according to specific needs.

control function

Circuit breaker control: It can control the operation of circuit breakers, including switch control and automatic reclosing function.

Automated control: Supports automated control functions such as automatic fault isolation, automatic power restoration, etc.

Monitoring and Diagnosis

Real time monitoring: Monitor the real-time data of the system's current, voltage, power, etc., and provide detailed system status information.

Event recording: Record and store fault events and operation logs to assist in troubleshooting and system analysis.

Waveform capture: Capture electrical waveform data for in-depth analysis to optimize system performance.

communication interface

Protocol support: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, etc., ensuring compatibility with other systems and devices.

Interface options: Equipped with Ethernet, RS-232, RS-485 and other interfaces for convenient data exchange and system integration.

user interface

Display screen: usually equipped with an LCD display screen, used to display system status, parameter settings, and alarm information.

Configuration tool: Provides graphical configuration tools to simplify user settings and system management processes.

High reliability and environmental adaptability

Industrial grade design: meets industrial standards, adapts to various harsh environmental conditions, and ensures long-term stable operation.

Wide temperature range: Suitable for different environmental temperatures to ensure the reliability of the system.

application area

transformer substation

Equipment protection: used for equipment protection and control in substations, ensuring the safe and stable operation of substations.

System Integration: Supports the integration and management of various devices within the substation, providing comprehensive protection and control solutions.

Distribution system

Feedline management: Provide feeder protection and control in the distribution system to optimize system performance.

Fault isolation: achieve effective fault isolation, reduce the range of system power outages, and improve system reliability.

Industrial power system

Key equipment protection: provides protection for key equipment in industrial power systems to prevent production interruptions caused by faults.

Power monitoring: Real time monitoring and management of the operational status of industrial power systems to improve system efficiency.

summary

The Multilin L90N02HKHF8LH6 relay panel is a powerful power system protection and control component with high-performance protection, control, monitoring, and communication capabilities. Its modular design, flexible configuration options, and high reliability make it widely applicable in substations, distribution systems, and industrial power systems.

Product image
