Product Details Introduction

Multilin FMOD136V08B3 is a relay module in the GE Multilin series, mainly used for protection, control, and monitoring in power systems. The following is detailed information about the relay, including its main functions, application areas, and characteristics:

Main features and functions

Protection function

Overcurrent protection: Equipped with overcurrent protection function, it can detect and respond to overcurrent situations in the system to prevent equipment damage.

Short circuit protection: Provides short circuit protection, quickly disconnects faulty circuits, and reduces damage to equipment and systems.

Overvoltage/undervoltage protection: protects equipment from the effects of high or low voltage, ensuring stable system operation.

Monitoring and Control

Real time monitoring: Continuously monitor the system status, provide real-time data and alarm information.

Control function: Supports automated control, such as switch control, circuit breaker operation, etc., to achieve automatic protection and recovery of the system.

communication interface

Multi protocol support: Supports multiple communication protocols, including Modbus, DNP3, IEC 61850, etc., to ensure compatibility with other systems and devices.

Interface options: Provides multiple communication interfaces, such as Ethernet, RS-232, RS-485, etc., for easy data exchange and system integration.

user interface

Display screen: equipped with an LCD display screen, used to display system status, parameter settings, and alarm information.

Configuration tool: Provides graphical configuration tools to simplify parameter settings and system management.

High reliability and environmental adaptability

Industrial grade design: Meets industrial grade standards and can operate stably in harsh environmental conditions.

Wide temperature range: Adapt to different environmental temperatures to ensure the reliability of the equipment under various operating conditions.

Diagnostic function

Event recording: Recording and storing important event and fault information helps with fault analysis and system maintenance.

Waveform capture: Capture electrical waveform data for detailed analysis and optimization of protection settings.

application area

transformer substation

Equipment protection: used in substations to protect equipment from damage caused by abnormal current or voltage.

System integration: As part of the substation protection system, it provides comprehensive protection, control, and monitoring functions.

Distribution system

Feedline protection: provides protection for feeders in the distribution system to prevent system problems caused by faults.

Automated Control: Supports automated control functions such as fault isolation and recovery, enhancing system reliability.

Industrial power system

Equipment protection: Provide protection for critical equipment in industrial power systems to ensure stable operation of the equipment.

Power monitoring: Real time monitoring of system status to help optimize operation and maintenance.

summary

The Multilin FMOD136V08B3 relay module is a high-performance protection, control, and monitoring device suitable for substations, distribution systems, and industrial power systems. Its powerful protection functions, rich communication interfaces, and high reliability design make it widely applicable in various industrial and power applications.

Product image
