Multilin 760-P5-G5-S5-H feeder management relay

Multilin 760-P5-G5-S5-H feeder management relay

Product Details Introduction

Multilin 760-P5-G5-S5-H is a feeder management relay in the GE Multilin series, mainly used for feeder protection, monitoring, and control in power systems. This relay provides advanced functions for the power distribution system, helping to ensure the stability and safety of the system. The following is detailed information about Multilin 760-P5-G5-S5-H:

Main functions and features

Feedline protection:

Overcurrent protection: Provides short-circuit and overload protection functions to prevent damage to the feeder due to overcurrent.

Instantaneous and Time Delay Function: Supports protection settings for instantaneous and time delays to meet different protection requirements.

Fault detection:

Fault location: Through high-precision fault detection technology, faults can be quickly located and isolated, improving system recovery speed.

Remote fault diagnosis: Supports remote fault diagnosis function for easy maintenance and management.

Monitoring and Control:

Real time monitoring: Provides real-time monitoring of parameters such as feeder current and voltage to ensure the normal operation of the system.

Control function: Supports remote control function, which can perform start stop control and other operations on the feeder.

Communication ability:

Integration: Integrated with the main relay and control system, supporting data exchange and system linkage.

Communication Protocol: Supports multiple communication protocols such as Modbus, DNP3, etc., making it easy to integrate with SCADA systems.

User interface:

Intuitive operation: Equipped with an intuitive user interface to simplify configuration and operation.

Event logging: Record and store event logs, providing detailed fault and operation records.

Environmental adaptability:

Durable design: With excellent anti-interference ability and durability, suitable for various industrial environments.

Temperature range: able to work stably within a wide temperature range and adapt to different environmental conditions.

Automation function:

Automatic reclosing: Supports automatic reclosing function, which can automatically reconnect the circuit after power supply is restored.

Automatic testing: equipped with automatic testing function to ensure the reliability of the system during operation.

application area

Power distribution system:

Feedline protection: Provide comprehensive feeder protection and monitoring in the power distribution system to ensure the stability and safety of the distribution network.

Fault isolation: Quickly isolate the fault area to improve the reliability and recovery speed of the distribution system.

power plant:

Power generation equipment protection: protects the feeder equipment in the power plant from damage caused by overcurrent and short circuit.

System integration: Integrate with other protection and control systems of the power plant to enhance the automation and management level of the system.

Industrial facilities:

Production line protection: used to protect and monitor feeders in industrial facilities, ensuring the smooth progress of the production process.

Equipment control: Achieve precise control and monitoring of industrial equipment to improve production efficiency.

Building Management:

Building power system: Provide feeder protection in the building's power system to ensure the normal operation of the building's power system.

Management function: Supports automation control and monitoring requirements in building management.

Water treatment facilities:

Water treatment equipment protection: used to protect the feeder equipment in water treatment facilities and ensure the stable operation of the water treatment process.

Fault management: Provide real-time monitoring and fault management functions to ensure the reliability of the system.

conclusion

The Multilin 760-P5-G5-S5-H feeder management relay provides powerful protection, monitoring, and control functions, suitable for various power distribution systems and industrial applications. Its high-precision fault detection, real-time monitoring, and automation functions enable it to effectively protect feeder equipment and improve the reliability and safety of the system.

Product image
