Multilin T60U03KHF8NH6 multi wire relay

Multilin T60U03KHF8NH6 multi wire relay

Product Details Introduction

The Multilin T60U03HHF8NH6 multi wire relay is an advanced relay in the GE Multilin series, designed to provide multifunctional power protection and control. It supports multi wire (or multi input) configuration, suitable for complex power systems and industrial applications. The following are the main application areas and functions of this relay:

Main functions:

Multi functional protection:

Overcurrent protection: Monitor and protect equipment from the effects of overcurrent.

Overvoltage and undervoltage protection: Ensure that the voltage is maintained within a safe range.

Frequency protection: Monitor the system frequency to prevent frequency anomalies.

Ground fault protection: detecting and responding to ground faults to protect the safety of equipment and systems.

Multi line configuration:

Supports multiple input channels, suitable for the protection and monitoring needs of complex power systems.

Provide flexible configuration options to meet the needs of various application scenarios.

Communication and integration:

Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850, for easy integration with upper level systems.

Provide remote monitoring and operation functions to facilitate user fault diagnosis and system management.

Data recording and analysis:

Record and store event logs and system data to assist in fault analysis and performance evaluation.

Provide graphical data analysis tools to support users in viewing and analyzing the status of the power system.

User interface and configuration:

Equipped with an easy-to-use interface that supports intuitive operation and configuration.

Provide detailed configuration options to meet different application requirements.

Application areas:

Substation protection:

Busbar protection: Monitor and protect the busbars within the substation to prevent the spread of busbar faults.

Transformer protection: provides overcurrent, overvoltage, and ground fault protection for transformers.

Circuit breaker protection: Monitor the status and operation of the circuit breaker to ensure its reliable operation.

Power plant protection:

Generator protection: protects the generator from overcurrent, overvoltage, undervoltage, and frequency anomalies.

Generator protection: Provides comprehensive protection to ensure the safe and stable operation of the generator set.

Power distribution system protection:

Line protection: Provides overcurrent, short circuit, and ground fault protection to ensure the safety of distribution lines.

Load management: Monitor and manage the load of the distribution network to prevent overload and equipment damage.

Industrial facility protection:

Factory power protection: Monitor and protect the power system within the factory to prevent equipment failures and production interruptions.

Mining and heavy industry: Protect mining and heavy industry equipment to ensure the safety and continuity of the production process.

New energy generation:

Wind farm: Monitor and protect the power generation equipment of the wind farm to ensure the stability of wind power generation.

Solar power station: provides overcurrent, overvoltage, and ground fault protection for the equipment of the solar power station.

Transportation:

Railway system: Protect railway power equipment and ensure the reliable operation of the railway system.

Subway and Light Rail: Provide protection for electrical equipment in subway and light rail systems to ensure safe operation.

Product image
