Product Details Introduction

The Multilin EP5P5B5HRR is a motor protection system in GE's Multilin series, designed to provide comprehensive protection and control functions for motors. The following is detailed information about the Multilin EP5P5B5HRR motor protection system:

Main features and functions

Motor protection function:

Overload protection: Real time monitoring of motor current to prevent motor damage caused by overload situations.

Blocked rotor protection: detects the blockage of the motor during startup and provides protection to prevent motor damage.

Phase loss protection: detects power supply phase loss or imbalance to prevent damage to the motor caused by phase loss.

Overvoltage/undervoltage protection: protects the motor from voltage fluctuations.

Short circuit protection: Monitor abnormal current conditions and provide short circuit protection to prevent motor damage.

Thermal protection: Prevent motor overheating through temperature monitoring and ensure the normal operation of the motor.

Ground leakage current protection: Monitor and protect against ground leakage current issues caused by insulation faults.

Monitoring and Diagnosis:

Real time monitoring: Provides real-time monitoring of current, voltage, power, and other key parameters.

Fault diagnosis: Record fault events and provide detailed diagnostic information to help quickly locate and solve problems.

Data recording: Store historical data and event records for subsequent analysis and auditing.

Communication and Integration:

Communication Protocol: Supports multiple industrial standard communication protocols, such as Modbus RTU, Modbus TCP/IP, DNP3, and IEC 61850, making it easy to integrate with other control systems.

Remote monitoring: Supports remote access and monitoring through communication interfaces, simplifying maintenance and management work.

User interface:

Display screen: Equipped with an LCD display screen for real-time display of the motor's operating status and parameters.

Operating Interface: A user-friendly interface that facilitates settings and adjustments.

Programmable: Provides programmable input/output options to meet specific application requirements.

Extended functions:

Multiple protection algorithms: Provide multiple protection algorithms to meet the protection needs of different types of motors.

Flexible configuration: It can be configured according to specific application requirements to ensure the flexibility and scalability of the system.

Product image
