Multilin M6P3KH motor management relay

Multilin M6P3KH motor management relay

Product Details Introduction

The Multilin M6P3KH is a motor management relay in the GE Multilin series, designed specifically for motor protection and control. It provides multiple protection functions to ensure the safety and reliability of the motor during operation. The following is detailed information about the Multilin M6P3KH motor management relay:

Main features and functions

Motor protection function:

Overcurrent protection: detects whether the motor current exceeds the set value and provides overcurrent protection to prevent motor damage.

Overload protection: Monitor the load condition of the motor, provide overload protection, and prevent damage to the motor during long-term overload operation.

Over temperature protection: Monitor the temperature of the motor to prevent damage or malfunction caused by overheating.

Ground fault protection: Detect ground faults in motors to prevent safety hazards caused by grounding issues.

Locking protection: Provide locking protection function to detect whether the motor is locked and take corresponding measures.

Monitoring and Diagnosis:

Real time data monitoring: Real time monitoring of motor parameters such as current, voltage, and power to ensure that the motor operates within the normal range.

Event recording: Record protection events, fault information, and alarm records for easy fault diagnosis and maintenance.

Self diagnostic function: Built in self diagnostic function, regularly checks the status of the equipment to ensure the normal operation of the system.

Communication and Integration:

Multiple communication interfaces: Supports RS-232, RS-485 and other communication interfaces, making it easy to integrate with other devices and systems.

Support standard communication protocols: compatible with industrial standard communication protocols such as Modbus and DNP3, achieving effective data transmission and integration.

User interface and configuration:

Display screen: Equipped with an LCD display screen, it clearly displays the motor operation status and protection parameters.

Configuration and Programming: Provides a user-friendly interface for easy configuration and programming, adjusting protection settings and operating parameters.

Remote Access: Supports remote access and management, allowing users to remotely monitor and control devices through the network.

High reliability design:

Industrial grade design: using industrial grade components to ensure the reliability and stability of equipment in harsh environments.

Redundant design: Provide redundant power input and signal paths to ensure that the equipment can still operate normally in the event of a main system failure.

Product image
