MULTILIN 12BDD18B1A Transformer

MULTILIN 12BDD18B1A Transformer

Product Details Introduction

MULTILIN 12BDD18B1A is a transformer protection device in the GE Multilin series. It is designed specifically for transformer protection, providing comprehensive protection, monitoring, and control functions to ensure the safe and stable operation of transformers. The following is detailed information about the MULTILIN 12BDD18B1A transformer protection equipment:

Main features and functions

Transformer protection function:

Overcurrent protection: detects whether the current of the transformer exceeds the set value, provides overcurrent protection to prevent the transformer from being damaged due to excessive current.

Overload protection: Monitor the load condition of the transformer, provide overload protection to prevent damage caused by long-term overload.

Differential protection: By comparing the input and output currents of transformers, differential protection is provided to detect internal faults and prevent further damage.

Grounding fault protection: Detecting grounding faults in transformers to prevent safety hazards caused by grounding issues.

Over temperature protection: Monitor the temperature of the transformer, provide over temperature protection, and prevent equipment damage caused by overheating.

Monitoring and Diagnosis:

Real time data monitoring: Real time monitoring of transformer parameters such as current, voltage, and power to ensure that the transformer operates within the normal range.

Event recording: Record protection events, fault information, and alarm records to assist in fault diagnosis and system maintenance.

Self diagnostic function: Built in self diagnostic function, regularly checks the operating status of the equipment to ensure the normal operation of the system.

Communication and Integration:

Multiple communication interfaces: Supports various communication interfaces such as RS-232, RS-485, Ethernet, etc., making it easy to integrate with other devices and systems.

Support standard communication protocols: compatible with industrial standard communication protocols such as Modbus and DNP3, achieving effective data transmission and integration.

User interface and configuration:

Display screen: Equipped with an LCD display screen, it intuitively displays the operating status and protection parameters of the transformer.

Configuration and Programming: Provides a user-friendly interface for easy configuration and programming, adjusting protection settings and operating parameters.

Remote Access: Supports remote access and management, allowing users to remotely monitor and configure devices through the network.

High reliability design:

Industrial grade design: using industrial grade components to ensure the stability and reliability of equipment in harsh environments.

Redundant design: Provide redundant power input and signal paths to ensure normal operation in the event of a main system failure.

application area

Power system: Suitable for transformer protection in power plants, substations, and distribution networks to ensure stable operation of the power system.

Industrial automation: used for transformer protection in industrial automation systems to enhance the level of intelligence and safety of the system.

Manufacturing: Applied in the manufacturing industry to protect critical transformer equipment and ensure stability and safety during the production process.

Product image
