Product Details Introduction

Multilin 339-E-P1-G1-H is a motor protection system in the GE Multilin series, designed to provide comprehensive motor protection, monitoring, and control functions. The following is detailed information about the Multilin 339-E-P1-G1-H motor protection system:

Main features and functions

Motor protection function:

Overcurrent protection: Monitor motor current and provide overcurrent protection to prevent damage to the motor when the current is too high.

Overload protection: Monitor the load condition of the motor and provide overload protection to avoid problems caused by overload of the motor.

Blocked rotor protection: Monitor whether the motor is in a blocked rotor state to prevent damage to the motor due to blocked rotor.

Over temperature protection: Monitor the temperature of the motor and provide over temperature protection to prevent equipment damage caused by excessive temperature.

Ground fault protection: Detect ground faults in motors to prevent safety hazards caused by grounding issues.

Startup protection: Protect the motor from damage caused by abnormal or excessive startup during the startup process.

Monitoring and Diagnosis:

Real time data monitoring: Real time monitoring of motor parameters such as current, voltage, power, temperature, etc., to ensure that the motor operates within a safe range.

Event recording: Record protection events and fault information to assist in fault analysis and equipment maintenance.

Self diagnostic function: Built in self diagnostic function, regularly checks the status of the equipment to ensure the normal operation of the system.

Communication and Integration:

Multiple communication interfaces: Supports various communication interfaces such as RS-232, RS-485, Ethernet, etc., facilitating integration with other devices and systems.

Support standard communication protocols: compatible with industrial standard communication protocols such as Modbus, DNP3, IEC 61850, etc., ensuring compatibility and reliability of data transmission.

User interface and configuration:

Graphic display screen: equipped with LCD or LED display screen, intuitively displaying the operating status and protection parameters of the motor.

User friendly configuration interface: Provides an easy-to-use configuration interface for setting and adjusting motor protection parameters.

Remote access and management: Supports remote access functionality, allowing users to remotely monitor and manage devices through the network.

High reliability design:

Industrial grade design: Using industrial grade components and designs to ensure the reliability and stability of equipment in harsh environments.

Redundant design: Provide redundant power input and signal paths to ensure that the equipment can still function properly in the event of a main system failure.

Product image
