PEPPERL+FUCHS HiD2082 Temperature Signal Regulator Module
Product Details Introduction
PEPPERL+FUCHS HiD2082 is a temperature signal conditioner module specifically designed to convert signals from temperature sensors such as thermocouples or RTDs into standardized current or voltage signals. This module is widely used in process control, automation, and industrial environments. Here are some key features and application information about the HiD2082 module:
Main features:
Signal conversion:
The HiD2082 module is capable of converting temperature signals from thermocouples or thermal resistors into standard analog output signals, typically 4-20 mA current signals or 0-10 V voltage signals. These standardized signals can be easily integrated into PLC, DCS, or other control systems.
high-precision:
This module has high-precision signal processing capabilities to ensure accurate conversion of temperature signals, thereby ensuring precise response of the control system to temperature changes.
Isolation protection:
HiD2082 provides isolation protection between input, output, and power supply to prevent electromagnetic interference and grounding circuit issues, ensuring the stability and safety of signal transmission.
Diagnostic function:
The module has built-in diagnostic function, which can monitor the status of sensors and signal lines, such as open circuit, short circuit, temperature range exceeding, etc., and provide alarm signals to help maintain and troubleshoot.
compatibility:
This module supports multiple types of thermocouples (such as J, K, T, etc.) and thermal resistors (such as PT100) for input, flexibly adapting to different temperature measurement needs.
Easy installation and configuration:
The HiD2082 module is designed for DIN rail installation, with a compact structure that is easy to integrate into control cabinets or industrial sites. The input type and output signal range can be easily adjusted through the dip switch on the front panel or software configuration.
Application areas:
Process control: widely used in industries such as petroleum, chemical, pharmaceutical, and food processing to monitor and control the temperature of critical processes.
Automation system: integrated into the automation system for real-time temperature monitoring and feedback control.
Industrial monitoring: providing reliable data support in industrial environments that require high-precision temperature measurement.
Product image
