Bently 3500/93 135785-02C System Monitor

Bently 3500/93 135785-02C System Monitor

Product Details Introduction

The Bently Nevada 3500/93 135785-02C system monitor is part of the 3500 series mechanical protection and condition monitoring system, specifically designed for vibration monitoring and diagnostic applications in industrial environments. This module serves as a system display, mainly used to provide visual display of system status, helping users monitor and diagnose equipment operation status.

main features

Real time data display: The 3500/93 system monitor can display real-time data from the 3500 series monitoring modules, including key parameters such as vibration, shaft displacement, and speed. This helps operators to monitor the real-time operation status of the equipment on site.

Multiple display modes: This monitor supports multiple data display modes, such as trend charts, bar charts, numerical displays, etc. Users can choose the most suitable display mode according to their needs.

User Interface: Provides a user-friendly interface, supports multilingual display, is easy to operate, and is easy to understand and use. Users can navigate and configure display content through the buttons and menu system on the front panel.

Data storage and retrieval: This display has a certain historical data storage capability, which can store key parameter changes over a period of time, facilitating subsequent fault analysis and trend prediction.

Modular design: As part of the 3500 series, the 3500/93 system monitor can seamlessly integrate with other 3500 series modules, ensuring compatibility and scalability of the entire system.

application area

Rotating machinery protection: widely used for monitoring rotating machinery (such as turbines, compressors, pumps, etc.) in industries such as petroleum, natural gas, power, and chemical, helping to prevent mechanical failures and reduce unexpected downtime.

Vibration monitoring: By displaying real-time vibration data, maintenance personnel can quickly identify abnormal states of equipment, take preventive maintenance measures, and extend the service life of equipment.

Factory automation: In the factory automation system, as part of the monitoring system, real-time monitoring of the operating status of key equipment is carried out to ensure the safety and reliability of the production process.

technical specifications

Display screen type: usually LCD or LED display screen, supporting high brightness and wide viewing angle display.

Resolution: High resolution display, capable of clearly displaying complex charts and data.

Communication interface: Supports communication with other modules in the 3500 series, usually through internal buses or dedicated interfaces for data transmission.

Power requirement: Usually 24VDC or powered through the backplane, with low power consumption.

Size and Installation: Modular design, compliant with 3500 series standard rack dimensions, easy to install and maintain.

Product image
