TRICONEX DI3301S2 Analog Input Module

TRICONEX DI3301S2 Analog Input Module

Product Details Introduction

Triconex DI3301S2 is an analog input module used in industrial control systems, typically applied in safety and automation systems of the Triconex series. The Triconex series is renowned for its high reliability and redundant design, and is widely used in critical applications in industries such as oil, gas, chemical, and nuclear power.

Main features and functions

Analog input:

The DI3301S2 module is mainly used to receive and process analog signals from various sensors or devices, such as temperature, pressure, flow rate, etc. These signals are usually standard industrial signals such as 4-20mA or 0-10V.

Redundancy and high reliability:

The Triconex series is known for its Triple Redundancy Architecture (TMR), which gives the module extremely high reliability and fault tolerance. Even if one module or channel malfunctions, the system can still operate normally.

Real time monitoring and diagnosis:

The module has self diagnostic function, which can monitor its working status in real time and issue warnings when problems occur for timely maintenance.

Environmental adaptability:

Designed to meet industrial standards and capable of stable operation under harsh environmental conditions such as high temperature, humidity, and high electromagnetic interference.

Compatibility with Triconex system:

This module seamlessly integrates with the Triconex safety system and can easily collaborate with other control modules to achieve complex process control and safety management functions.

Technical specifications (example)

Input channel:

Support multi-channel analog input, the specific number of channels and signal types depend on the module configuration.

Signal type:

Usually supports industrial standard analog signals such as 4-20mA and 0-10V.

Power requirements:

Typical DC power input requirements (such as 24V DC) depend on the system configuration.

Communication interface:

Connected to other parts of the Triconex system through proprietary communication protocols to ensure the reliability and speed of data transmission.

Work environment:

Suitable for industrial environments with a wide temperature range, it has characteristics such as earthquake resistance, moisture resistance, and dust prevention.

Size and installation:

Modular design, suitable for installation in standard control racks or cabinets, facilitating system expansion and maintenance.

Product image
