TriconeX A03481S2 Triple Redundant Processor

TriconeX A03481S2 Triple Redundant Processor

Product Details Introduction

Triconex A03481S2 is a triple redundant processor module that is an important component of the Triconex series of security systems. This module is designed specifically for industrial environments with critical tasks and high security requirements, utilizing a Triple Modular Redundancy (TMR) architecture to provide highly reliable control and protection functions.

Main features and functions

Triple Modular Redundancy (TMR) architecture:

The A03481S2 module adopts TMR architecture and consists of three independent, parallel processing units. Each processing unit processes the same task simultaneously, and the final output is determined through a voting mechanism to ensure that the system can operate normally even when one processing unit fails. This design greatly improves the reliability and safety of the system.

High security:

The module complies with SIL 3 safety level and is an ideal choice for high safety applications. It provides excellent fault detection and fault tolerance capabilities in industrial automation and safety protection systems, ensuring reliable operation of the system in critical tasks.

Real time processing and control:

A03481S2 has powerful real-time processing capabilities, capable of handling complex control logic and large-scale data input and output, meeting the fast response requirements of industrial automation.

Multiple communication interfaces:

Support communication interfaces with various I/O modules and other control systems, such as Modbus, Ethernet/IP, etc., to ensure efficient and stable data transmission.

Modular design:

The processor module adopts a modular design, which facilitates system expansion and maintenance. Users can flexibly configure the system according to specific needs to ensure that it meets the requirements of different application scenarios.

Self diagnostic function:

The built-in self diagnostic function can monitor the running status of the module in real time, detect and report potential problems in a timely manner, and facilitate maintenance personnel to respond quickly.

technical specifications

Processor architecture:

Triple Modular Redundancy (TMR), where each module independently handles the same task and the voting mechanism ensures the reliability of the output.

Security level:

Meets SIL 3 safety level requirements and is suitable for applications with high safety requirements.

Communication interface:

Supports multiple industrial standard communication protocols, such as Modbus, Ethernet/IP, etc., and can seamlessly integrate with various I/O modules and other systems.

Power requirements:

Usually requires a 24V DC power supply, specific power requirements may vary depending on system configuration.

Environmental adaptability:

Design to adapt to various challenges in industrial environments, such as high temperature, humidity, vibration, and electromagnetic interference.

Product image
