MTL 8502-B1-DP Bus Interface Module

MTL 8502-B1-DP Bus Interface Module

Product Details Introduction

The MTL 8502-B1-DP bus interface module is an interface device produced by MTL Instruments for use in industrial automation and process control systems. This module is mainly used to achieve effective communication between industrial field devices and control systems, especially in application scenarios using fieldbus technology. The following is a detailed introduction to the main features, functions, and application areas of this module.

Main features and functions

Bus interface:

MTL 8502-B1-DP is a Profibus DP (Decentralized Peripherals) bus interface module designed specifically for Profibus DP networks, providing a communication interface between fieldbus devices and control systems.

High speed data transmission:

Support high data transmission rates to ensure fast and efficient data exchange between on-site devices and control systems, suitable for industrial applications that require real-time control.

Multi device connection:

Support multiple on-site device connections, able to integrate and manage multiple input/output devices, achieving centralized control and monitoring.

Easy to configure and maintain:

Provide intuitive configuration tools and diagnostic functions to facilitate system settings, troubleshooting, and maintenance operations for users.

Redundant design:

Design with redundant functions to enhance system reliability and stability, ensuring that the system can still operate normally in the event of a failure.

High environmental adaptability:

Adopting industrial grade design, it can work stably in various harsh environments and has good anti-interference ability.

technical specifications

Bus protocol:

Profibus DP， Compliant with Profibus international standards, supporting efficient data exchange and device control.

Data transmission rate:

Supports data transmission rates of up to 12 Mbps, suitable for high-speed data communication applications.

Working voltage:

Usually supports 24 VDC power supply, meeting the power requirements of industrial field equipment.

Environmental temperature:

The working temperature range is usually -20 ° C to+60 ° C, suitable for various industrial environmental conditions.

Connection method:

Provide standard Profibus DP connection interface for connecting to bus networks and field devices.

Product image
