1. “Run w/Load” mode (Discrete Input #3) a. And the Generator is stable (Generator Stable Delay time has been achieved)

 2. “Test” mode will NOT energize the “Generator Breaker Trip (open)” relay The EGCP-2 will DE-ENERGIZE to open the Generators Breaker. The output will stay de-energized until one of the two conditions is met.

Idle/Rated SwitchWhen selected as an Idle/Rated switch, the output must be connected to the engines speed control. This relay is de-energized to select an idle speed settings, and after reaching the set idle speed value and holding at that point for the set amount of time, the relay energizes to select the speed controls rated speed setting. The speed value and time are configured in the Engine Control menu under items “Idle Speed” and “Idle Time”.

Discrete Output 11—Audible Alarm

With the relay de-energized, this output has Normally Open (NO) terminals 31 and 32 and Normally Closed (NC) terminals 32 and 33 contacts to select from. The “Audible Alarm” relay output can be utilized as an option to control a plant Alarm Horn to indicate when an alarm condition has been sensed by the EGCP-2 control. This relay energizes upon any sensed alarm condition and will remain energized until an acknowledged command is given. Refer to chapter 2 for information on acknowledging and committing alarms. When an alarm set point is configured for Audible Alarm, the alarm condition will cause the audible and visual alarm output relays to energize and the red LED on the face of the EGCP-2 to flash. All alarm indicators will remain active until the alarm condition is acknowledged. No control actions occur as a result of an audible alarm condition.

Discrete Output 12—kVA Load or Idle/Rated Switch

This relay uses Normally Open (NO) contacts at terminal 34 and 35. Discrete Output #12 can be configured for a “KVA Load” or an “Idle/Rated” switch. This selection is done in the Configuration menu under “Relay #12 Function”. KVA Load Switch This relay will energize when the controls kVA value is within the configured Low and High settings. The relay will de-energize when the kVA value is below or above the configured Low and High settings. The low and high set points are configured in the Real Load Control menu, under items “kVA Switch Low” and “kVA Switch High”.
