REXROTH DKC11.3-100-7-FW servo controller

REXROTH DKC11.3-100-7-FW servo controller

Product Details Introduction

The REXROTH DKC11.3-100-7-FW servo controller is a high-performance servo controller launched by Bosch Rexroth in Germany. The product has multiple superior performance characteristics and is widely used in the field of industrial automation. The following is a detailed introduction to the servo controller:

1、 Product Overview

Model: DKC11.3-100-7-FW

Brand: Bosch Rexroth

Type: Servo Controller

Application areas: Mainly used in equipment such as machine tools, robots, and automated production lines in the field of industrial automation.

2、 Main features

High precision control:

Through advanced digital control technology and high-speed feedback control algorithms, high-precision motion control can be achieved.

The servo motor is equipped with a high-performance angle measurement encoder, which can accurately measure the position of the rotor and the speed of the motor, thereby achieving precise positioning and speed control.

Multifunctionality:

Having multiple control modes and programming methods, it can adapt to different application scenarios and requirements.

Different programming languages and development tools can be used for program development and control logic implementation, improving the flexibility and customizability of devices.

Programmability:

The powerful programming capabilities enable users to develop and modify programs according to their actual needs, implementing complex control logic and algorithms.

Reliability:

Equipped with powerful fault detection and protection functions, it can monitor the operating status of equipment in real time, and promptly alarm and shut down in case of faults, ensuring the stable operation and efficient work of the equipment.

Power devices commonly use drive circuits designed with intelligent power modules (IPM) as the core, which integrate drive circuits and various fault detection and protection circuits internally, improving the reliability and safety of the equipment.

Advanced design:

The servo drive adopts a digital signal processor (DSP) as the control core, achieving digital, networked, and intelligent control.

The rectification part rectifies the input power supply through a three-phase full bridge rectification circuit to obtain a stable and ripple free DC power supply; The inverter part drives the IGBT through SPWM signal, converting the DC power supply into SPWM waveform to drive the servo motor.

Product image
