Product Details Introduction

Regarding the REXROTH CSB01.1N-PB-ENS-NNN-NN-S-NN-FW servo controller, the following is a detailed overview of the information:

1、 Basic Information

Model: CSB01.1N-PB-ENS-NNN-NN-S-NN-FW

Brand: Bosch Rexroth

Origin: Germany

2、 Product Features

Control core: Using a digital signal processor (DSP) as the control core, it can perform the functions of position, speed, torque, and current controllers, and achieve complex control calculations.

Drive circuit: Power devices commonly use drive circuits designed with intelligent power modules (IPM) as the core, which integrate the drive circuit internally and have fault detection and protection circuits for overvoltage, overcurrent, overheating, undervoltage, etc.

Inverter technology: By rectifying the AC power supply into a DC power supply, the inverter converts the DC power supply into SPWM waveform to drive the servo motor.

Encoder: The servo motor is equipped with a high-performance angle measurement encoder, which can accurately measure the position of the rotor and the speed of the motor.

3、 Interface and Configuration

Communication interface: Supports multiple communication interfaces such as PROFIBUS bus (PB), Sercos, EtherCAT, etc., making it easy to integrate with different systems.

Configuration options:

ENS=Encoder indraDyn/Hiperface/1 VSS/TTL

NNN=Not equipped (in certain option positions)

S=Standard Control Panel

4、 Application Fields

The REXROTH CSB01.1N series servo controller is suitable for various industrial automation fields, such as machine tools, production lines, robots, etc., and can meet the needs of motion control in different application scenarios.

Product image
