Product Details Introduction

Regarding the REXROTH DDS02.1-W150-D excitation driver, the following is a detailed overview of the information:

1、 Basic Information

Brand and Model: REXROTH (Bosch Rexroth) DDS02.1-W150-D

Type: Servo Control Drive Unit

Application areas: Widely used in industrial automation systems, such as injection molding machines, textile machinery, packaging machinery, CNC machine tools, and other fields.

2、 Technical features

Modular design: The servo drive adopts modular design, and the basic unit uses various modules to meet different functional requirements.

Control mode: It can be controlled through various methods such as Sercos, analog input, or DLC single axis control card.

Installation and Protection: This product and its power unit are designed to be installed inside a control cabinet or enclosed enclosure, meeting protection requirements of IP10 and complying with DIN40050 standards.

Signal transmission: Analog signals are routed through shielded wires, and all signal lines should use plug-in fixtures or miniature D-type connector plugs to facilitate unit replacement.

3、 Performance parameters

Rated current: 150A (specific value may vary depending on different configurations or measurement standards)

Current compensation: 150mA (+15V, -15V), 200mA (24V) (may vary depending on the source)

Peak current: DDS series drivers have 14 different power ranges, ranging from 15A to 200A peak current

Environmental temperature:+0...+45 ℃

Storage temperature: -30...+85 ℃

Transportation temperature: -30...+85 ℃

Protection level: IP20 (may reach IP10 after installation)

Weight: Approximately 7.5kg (weight values may vary from source to source)

4、 Other information

Cooling method: using air cooling

Feedback method: Equipped with digital servo motor feedback

Installation method: Control room installation

Structural form: modular

Product image
