Rexroth DKC11.3-040-7-FW servo drive

Rexroth DKC11.3-040-7-FW servo drive

Product Details Introduction

The Rexroth DKC11.3-040-7-FW servo drive is a high-performance servo drive produced by Bosch Rexroth, which has a wide range of applications in modern industrial automation. The following is a detailed introduction to the servo drive:

1、 Product Overview

Brand and Model: Rexroth (Bosch Rexroth) DKC11.3-040-7-FW

Type: Servo Drives, also known as servo controllers or servo amplifiers

Application areas: Mainly used in high-precision positioning systems, such as industrial robots, CNC machining centers, and other automation equipment

2、 Technical features

Control core: Using a digital signal processor (DSP) as the control core, it can implement complex control algorithms, achieve digitization, networking, and intelligence.

Power drive: Power devices commonly use intelligent power modules (IPM) as the core design of the drive circuit, integrating the drive circuit and various fault detection and protection circuits (such as overvoltage, overcurrent, overheating, undervoltage, etc.) to ensure the stable operation of the drive.

Control mode: Supports position control, speed control, and torque control to meet the needs of different application scenarios.

Position control: Control the speed, angle, and torque of the motor, and precisely control the speed and angle through pulse trains.

Speed control: Only controls the speed and torque of the motor, and the angle is controlled by external feedback signals.

Torque control: Only controls the torque of the motor, and the torque magnitude is set through analog input or communication.

Communication method: Supports modern communication methods such as Ethernet, facilitating data exchange and control with the host computer or other devices.

Protection level: IP54, with certain dustproof and waterproof capabilities, suitable for various industrial environments.

3、 Performance parameters

Origin: Germany

Output frequency: 50Hz

Voltage type: alternating current (AC), typically 220V

Encoder type: incremental encoder, encoder accuracy can reach 60000 pulses/s

Installation method: bolt installation

Applicable altitude: below 3000 meters

Product image
