The first time the power level decreases below the Minimum Reverse Power setting does not last long enough to cause a trip. The second time the accumulating amount reaches the calculated delay and a trip is received. Dropping below Reverse Power Level would cause a trip instantly.

Reverse KVAR Limit

 • Range: –.0 to –00

• Set as a percentage of the Rated kVAR. If the EGCP-2 senses a kVAR load greater than this value the Reverse kVAR Delay begins. When the Delay times out, an alarm will trigger.

• Used to indicate loss of field excitation to the generator.

Reverse KVAR Delay

• Range: 0.1 to 5.0 seconds.

• Provides a delay before triggering the Alarm.

Remote Faults #1 through #6

 • Each fault is programmable for: disabled warning visual alarm audible alarm soft shutdown hard shutdown Remote Faults #1 through #6:

• Each alarm has a programmable time delay (0 to 30 seconds).

• Each alarm can be set for any of the standard alarm or shutdown levels.

 • Remote Faults 1 and 2 can have a Stable Delay time Enabled or Disabled. When Enabled a 15 second timer will begin after the Gen Stable period has expired.

Preglow Time

• Time of preglow allowed prior to engine crank cycle.

• Maintained through engine cranking.

• Resets after every crank attempt.

Crank Time

• Maximum Allowable Time for Engine Cranking. Crank Cutout

• Engine rpm level where crank command is canceled.
