PP877K 3BSE069274R1 Touch screen

Low Oil Pressure

 • Used to sense failure of lube oil system.

• Start Sequencing ENABLED, Active at 90% of Rated Speed plus 5 seconds or when Generator Breaker closes plus 5 seconds.

 • Start Sequencing DISABLED, Active when Fuel Solenoid output energizes plus 30 seconds or when Generator Breaker closes plus 5 seconds High H2O Temperature Pre-Limit

• Uses engine mounted temperature sensor

• Active once Generator is stable.

• Display is selectable for degrees F (American) or degrees C (Metric).

High H2O Temperature

• Uses engine mounted temperature sensor.

• Active once Generator is stable.

 • Display is selectable for degrees F (American) or degrees C (Metric). Low H2O Temperature

• Useful for detection of failed jacket water heater.

• Always active.

Synchronizer Mode Permissive

• Acts as a synch check device.

• EGCP-2 will not issue speed or voltage bias commands, but if synchronization conditions are within spec (phase and voltage), control will issue a breaker close command. Check

• Used for checking synchronizer prior to commissioning.

• EGCP-2 control actively synchronizes generator by issuing speed and voltage bias commands, but does not issue breaker closure command.
