Process Droop

 • Introduces negative feedback on the process reference as the process input increases.

• Used to add stability to marginally stable processes. Process Filter

• Low Pass Filter attenuates higher frequency transients on process 4–20 mA input signal.

• The higher the filter is set, the more active the process control will be to higher frequency process transients.

• The lower the filter is set, the less active, and more stable the process control will be to higher frequency process transients.

Process Reference

• The reference point at which the master will control the process input.

• The reference point units are selectable under Process Units.

 • Also used in Soft Transfer modes to set the level of process at which the transfer from mains to generator(s) will occur.

• Rate, in %/s, at which the process reference will change when the EGCP-2 receives a Raise Load input (Discrete Input #6) or Modbus address AW40328 while operating in process control mode.

• Rate, in %/s, at which the process reference will change when the EGCP-2 receives a Lower Load input (Discrete Input #7) or Modbus address AW40328 while operating in process control mode.

Process High Limit

• Maximum allowable process reference level.

 • Dependent on Process Units setting.

• Effective on active master unit only. Process High Limit Alarm

• Sets Alarm Action when process High Limit is reached. Process Low Limit

• Minimum allowable process reference level.

• Dependent on Process Units setting.

• Effective on active master unit only. Process Low Limit Alarm

 • Sets Alarm Action when process reference reaches the Low Limit.
