Siemens 6ES5188-3UA22 central rack

Siemens 6ES5188-3UA22 central rack

Product Details Introduction

Siemens 6ES5188-3UA22 is the central rack in the SIMATIC S5 series, used to accommodate and connect various controller modules, I/O modules, and other expansion modules. It serves as the core framework of the entire system, providing electrical connections and physical support to ensure reliable communication and stable operation between system modules.

Main features:

Module capacity:

6ES5188-3UA22 is designed to accommodate multiple SIMATIC S5 series modules, including CPU modules, I/O modules, communication modules, etc. It provides a modular slot structure for easy installation and configuration of different modules.

Power and signal distribution:

The central rack has power and signal distribution functions, ensuring that all modules installed on the rack can receive stable power supply and achieve signal communication between modules through the backplane bus.

Bus architecture:

The rack is equipped with a built-in backplane bus, which is used to connect various modules to the main controller. The bus architecture supports high-speed data exchange between modules, ensuring fast transmission of control instructions and feedback information.

Robust industrial design:

This rack has a sturdy industrial grade design, suitable for harsh environments, able to withstand vibration, dust, and temperature fluctuations, ensuring long-term stable operation.

Flexible scalability:

As a central rack, it supports connections with other expansion racks or devices, allowing users to expand the system's control range and processing capabilities according to their needs.

Product image
