Siemens 6ES5490-8MB21 front connector

Siemens 6ES5490-8MB21 front connector

Product Details Introduction

Siemens 6ES5490-8MB21 is the front connector module of Siemens S5 series PLC. This module is used to provide front-end connection interfaces for various modules of the PLC, ensuring electrical connections with other modules or external devices.

Main features:

Series: S5 Series

Model: 6ES5490-8MB21

Type: Front connector

Function: Provides a front-end connection interface with PLC modules for connecting signal lines or cables.

Functional features:

Interface function: As the front connector of the PLC module, it is used to connect signal lines or cables to the front of the PLC module for easy wiring and maintenance.

Module compatibility: Designed to work with standard modules from the Siemens S5 series to ensure compatibility and stability.

Easy to install: Front connector modules typically have a design that is easy to install and remove, making the connection and replacement process more efficient.

Application scenarios:

Industrial automation: used in PLC control systems to connect signal lines between PLC modules and external devices.

Device Connection: Used to connect and manage cables between multiple PLC modules and external devices, supporting complex control systems.

System maintenance: Simplify the connection between PLC modules and external devices for easy maintenance and system expansion.

Technical parameters:

Applicable modules: Compatible with digital and analog input/output modules of the S5 series.

Connection method: The front connector usually uses screw type or spring type terminal blocks to provide a stable connection.

Electrical performance: The design ensures good electrical contact and signal transmission, reducing interference and signal loss.

Usage precautions:

Wiring specifications: Connect wires according to the connector's wiring diagram to ensure correct and reliable electrical connections.

Installation inspection: Ensure that the front connector module is securely installed and the wiring terminals are not loose.

Maintenance management: Regularly check the connection status, keep the connection clean, avoid signal interference and connection failures.

Product image
