Siemens 6ES5241-3DA12 Data Acquisition Module

Siemens 6ES5241-3DA12 Data Acquisition Module

Product Details Introduction

Siemens 6ES5241-3DA12 is a data acquisition module in the SIMATIC S5 series, used for data acquisition and processing in industrial automation systems. This module is particularly suitable for application scenarios that require converting analog signals into digital data, and is widely used in various measurement, monitoring, and control tasks.

Main features:

Model: 6ES5241-3DA12

Series: SIMATIC S5 Series

Module type: Data Acquisition Module

Main functions:

Analog signal conversion: Convert analog signals (such as voltage or current signals) into digital signals for processing by PLC.

Multi channel input: Supports multiple channels of input, allowing the module to simultaneously process data from multiple sensors or signal sources.

High precision: Provides high-precision analog-to-digital conversion to ensure data accuracy.

Real time data collection: capable of real-time collection and processing of signal data for monitoring and control applications.

Application scenarios:

Process control: In the fields of chemical, pharmaceutical, food processing and other process control, it is used to collect and monitor various parameters in the production process.

Measurement system: Used in various measurement systems to collect analog signals from sensors, such as temperature, pressure, flow rate, etc.

Data monitoring: used for real-time monitoring of the status of equipment and systems, conducting data analysis and alerting.

Advantages:

Accurate data collection: capable of providing high-precision data conversion to ensure the accuracy and reliability of system control.

Flexible configuration: Supports multi-channel input to meet different application requirements.

Integration with PLC: Seamless integration with SIMATIC S5 series PLC simplifies system design and maintenance.

Technical specifications:

Input channels: Usually support multiple analog input channels, the specific number depends on the module design.

Conversion accuracy: Provides high-precision A/D conversion, typically with a conversion accuracy of 12 bits or higher.

Signal type: Supports multiple analog signal types, including voltage, current, etc.

Power requirements: Powered by the system bus or an independent power source, the specific power requirements depend on the system configuration.

Data transmission: Data transmission is achieved through communication interface with PLC to ensure real-time data processing and transmission.

Product image
