HONEYWELL CC-TAID01 51306733-175 base module

When performing any work (installation, mounting, startup), all instructions given by the manufacturer and in particular the safety instructions provided in these Installation and Commissioning Instructions are to be observed.

 ► The Excel 800 System (including the XCL8010 Controller Module, I/O modules, manual disconnect modules, and the auxiliary terminal packages) may be installed and mounted only by authorized and trained personnel.

 ► Rules regarding electrostatic discharge should be followed.

► If the Excel 800 System is modified in any way, except by the manufacturer, all warranties concerning operation and safety are invalidated.

General Safety Information

Make sure that the local standards and regulations are observed at all times. Examples of such regulations are VDE 0800 and VDE 0100 or EN 60204-1 for earth grounding.

► Use only accessory equipment which comes from or has been approved by Honeywell.

 ► It is recommended that devices are to be kept at room temperature for at least 24 hours before applying power. This is to allow any condensation resulting from low shipping/storage temperatures to evaporate. ► The Excel 800 System must be installed in such a manner (e.g., in a lockable cabinet) as to ensure that uncertified persons have no access to the terminals.

Purpose

The Excel 800 System is an independently mounted electronic control system with fixed wiring. It is used for the purpose of building HVAC control and is suitable for use only in non-safety controls for installation on or in appliances.An Excel 800 System consists of the XCL8010 Controller and various I/O modules. The XCL8010 Controller provides interface connections, which allow connection to external systems. Auxiliary parts enable special features.
