Siemens 6ES5243-1AA11 Analog Input Module

Siemens 6ES5243-1AA11 Analog Input Module

Product Details Introduction

Siemens 6ES5243-1AA11 is an analog input module in the SIMATIC S5 series, used to convert analog signals into digital signals for further processing and analysis by PLC. This module is very suitable for applications that require precise monitoring and control in various industrial automation systems.

Main features:

Model: 6ES5243-1AA11

Series: SIMATIC S5 Series

Module type: Analog Input Module

Main functions:

Analog signal conversion: Convert analog signals (such as voltage or current signals) from external sensors or instruments into digital signals for PLC processing.

Multi channel input: Supports multiple input channels and can simultaneously process data from multiple signal sources.

High precision: Provides high-precision analog-to-digital conversion to ensure the accuracy of data acquisition.

Real time data processing: capable of real-time acquisition and processing of analog signals, suitable for dynamic control applications.

Application scenarios:

Process control: used in fields such as chemical, pharmaceutical, and food processing to monitor and control various parameters in the production process in real-time, such as temperature, pressure, and flow rate.

Measurement system: Collecting data from sensors such as temperature sensors, pressure sensors, etc. for precise measurement and control tasks.

Data monitoring and analysis: Real time monitoring of equipment status, analyzing data to make alarms or control decisions.

Advantages:

High precision data collection: ensuring the accuracy of data collection, improving the reliability and control precision of the system.

Flexible configuration: Supports multiple types of analog signal inputs to meet different application requirements.

Easy integration: Seamless integration with other modules and systems in the SIMATIC S5 series simplifies system design and maintenance.

Technical specifications:

Input channels: Typically, 8 analog input channels are provided, depending on the module design.

Input signal type: Supports multiple signal types, including voltage (such as 0-10V) and current (such as 4-20mA). Please refer to the technical documentation of the module for specific supported signal types.

Conversion accuracy: Generally provides a conversion accuracy of 12 bits or higher.

Power requirements: Powered by the system bus or an independent power supply. Please refer to the relevant technical manual for specific power requirements.

Data transmission: Data transmission is carried out through the communication interface of PLC to ensure real-time data processing and transmission.

Product image
