Siemens 6ES5434-4UA12 Digital Input Module

Siemens 6ES5434-4UA12 Digital Input Module

Product Details Introduction

Siemens 6ES5434-4UA12 is a digital input module in the SIMATIC S5 series, designed to receive and process external digital signals. This module is used to convert switch signals from industrial sites into digital signals that can be processed by PLCs.

Main features:

Model: 6ES5434-4UA12

Series: SIMATIC S5

Module type: Digital Input Module

Function:

Signal reception: Receive switch signals from external devices such as switches and sensors.

Signal conversion: Convert external digital signals into signals that can be processed by PLC.

Data collection: Provide input signals to PLC for data processing, control, and monitoring.

Application scenarios:

Industrial automation: In automation control systems, it is used to collect switch signals, control equipment or monitor status.

Process control: used to collect switch status signals during the production process, such as limit switches, buttons, etc.

Data collection: used to transmit signals from various sensors and switches to PLC for further data processing and control decision-making.

Technical specifications:

Channel count: Typically provides multiple input channels, specifically 16 digital input channels.

Input signal type: Supports 24V DC switch signal, compatible with industrial standard voltage.

Electrical specifications:

Input voltage: typically 24V DC.

Current specification: The input current of each channel is usually within the range of mA.

Interface standard: Compliant with SIMATIC S5 series interface standards and compatible with other S5 series modules.

Installation and use:

Installation: Install the 6ES5434-4UA12 input module into the SIMATIC S5 series rack and make electrical connections through the rack's backplane.

Configuration: Use STEP 5 programming software to configure the module, including setting input channel parameters.

Debugging: After installation, system debugging is required to ensure that the module can correctly receive and process input signals.

Product image
