Siemens 6ES5460-4UA13 Analysis Input Module

Siemens 6ES5460-4UA13 Analysis Input Module

Product Details Introduction

Siemens 6ES5460-4UA13 is an analytical input module in the Siemens SIMATIC S5 series. This module is used to collect and process analog signals from various sensors, converting these signals into data that can be processed by PLC systems to support complex industrial automation and process control applications.

Main features:

Model: 6ES5460-4UA13

Series: SIMATIC S5

Module type: Analog Input Module

Function:

Analog signal acquisition: Collecting data from sensors or other analog signal sources and converting it into digital signals for PLC processing.

Signal processing: Analyze and process the collected signals to provide accurate input data for control and monitoring.

Interface compatibility: Compliant with SIMATIC S5 series standard interfaces, ensuring compatibility with other modules and system components.

Technical specifications:

Channel count: Typically configured with 4 analog input channels.

Input signal type:

Supports different types of analog signals, such as voltage (e.g. 0-10V) or current (e.g. 4-20mA).

Has a certain input range and accuracy to meet different application requirements.

Resolution and accuracy: Provides high-precision analog signal acquisition, with specific resolution and accuracy depending on the module design.

Interface standard: Complies with SIMATIC S5 series standard interfaces and supports interoperability with other S5 series modules.

Application scenarios:

Industrial automation: used to collect and analyze various analog signals on the production line, such as temperature, pressure, flow rate, etc.

Process control: Real time monitoring and adjustment of process parameters during the production process to ensure the stability and accuracy of the process.

System integration: As a part of the PLC system, it collaborates with other modules and devices to complete complex automation control tasks.

Installation and use:

Installation: Install the 6ES5460-4UA13 module into the SIMATIC S5 series rack and connect it to other modules through the rack backplane.

Configuration: Use STEP 5 programming software to configure the module, set input channel parameters and data processing logic.

Debugging: After installation, perform system debugging to ensure that the module can correctly collect and process analog signals, and is compatible with other components of the system.

Product image
