FBM214 Analog input module

The XS814 Auxiliary Terminal Package can be mounted on any pluggable I/O module. The XS830 and XS831 Auxiliary Terminal Packages are suitable for mixed I/O modules, only. Specifically, they can be mounted on the top and/or bottom of the XF830A and on the bottom of the XFU830A. For reasons of mechanical stability, a maximum of two rows of Auxiliary Terminal Packages may be mounted together on any given I/O module.

► Push the auxiliary terminal package onto the grooves of the corresponding terminal socket / the mixed I/O module.

► Open the red lock mechanism by sliding it to the left and then gently pull the electronic module out of the terminal socket.

Push down the catch of the auxiliary terminal package and pull it out of the grooves of the terminal socket / the mixed I/O module.

Mounting/Dismounting Cross Connectors

Note The long cross connector (incl. in the scope of the delivery) can be mounted to the XS824-25 or XSU824-25, as required (see Fig. 29). It can be dismounted (see Fig. 28) and, if desired, replaced with one or two short connectors (optional accessory, see Table 5 on page 7). It is not permitted to replace these cross connectors with wire.

► Insert a screwdriver on one end of the cross connector and swivel it to the right and to the left.

► Insert a screwdriver on the other end of the cross connecter and swivel it to the right and to left until the cross connector is released.

► If desired, insert another cross connector.

Mounting/Dismounting Swivel Label Holders

Note A swivel label holder is included in the scope of delivery of each module. Use only the (short / long) swivel label holders appropriate for the given type (pluggable or mixed, respectively) of I/O module. Mounting Swivel Label Holders

► Snap the swivel label holder onto the hinges of the terminal socket / mixed I/O module.

► Apply self-adhesive labels to the holders.
