ABSOPULSE 80026-173-23 MOX12-P3509 module

Connecting the XI882A Operator Interface

 ► Connect the XI882 Operator Interface to the HMI interface of the XCL8010 Controller Module by means of – the XW882 cable or – the XW586 cable connected with an XW585 cable. For cable details, refer to section "Preconfigured Connection Cables" on page 11. Connecting Laptops (XL-Online/CARE)

► Connect a laptop (on which e.g., XL-Online or CARE has been installed) to the HMI interface or to the LONWORKS interface of the XCL8010 Controller Module by means of – the XW885 cable or – the XW585 cable connected with an XW586 Cable. For cable details, refer to section "Preconfigured Connection Cables" on page 11.

Connecting Modems

An Excel 800 System can be connected to a modem or an ISDN terminal adapter via the Modem Interface of the XCL8010 Controller Module by means of the XW586 cable.

 ► Connect the RJ45 female connector of the XW586 cable to the modem interface of the XCL8010 Controller.

 ► Connect the 9-pin sub-D connector to the modem. For cable details, refer to section "Preconfigured Connection Cables" on page 11. Refer to Appendix 2 for details regarding remote communication.

► On the controller side, connect the shield to terminals 7 and 10.

► On the side of the device, connect the shield to the respective terminals. Do not connect it to the cabinet ground or any other ground points.

LONWORKS Interface and Terminals

 The XCL8010 Controller Module features • An RJ45 socket serving as an interface to connect laptops to the LONWORKS Bus • LONWORKS terminals 11, 12, 13, and 14 to connect LONWORKS Bus I/O modules or other LONWORKS devices to the XCL8010 Controller or other LONWORKS controllers.The XCL8010 Controller Module is equipped with a LONWORKS service button and corresponding LONWORKS Service LED (status: yellow/OFF).
