If configured for temperature sensor input (but not from PT1000-2 temperature sensors), this network variable output represents the temperature for the appropriate input. Range: see Table 44 and Table 45 on page 40.Temperature#2 Sensor Output – nvoAiTemp[ ] If configured for temperature sensor input (from PT1000-2 temperature sensors, only), this network variable output represents the temperature for the appropriate input. Range: see Table 44 and Table 45 on page 40.Default Value The default value is set after power-up or reset and remains until the module has measured a valid value. nvoAiValuePct = INVALID = 0x7FFF (=163.835%) The sensor failure behavior can be configured for 2 … 10 V.

XFL(R)822 Analog Output Module

 For the XFL822/XFLR822 Analog Output Module, the LONMARK open-loop actuator object has been assigned per output. Each analog output object has its own configuration properties, except for heartbeat configuration and nciAoConfig, which will be shared among all objects.This value represents the current status of the analog output including feedback related to manual override initiated from the manual override. This is typically used for monitoring purposes at a supervisory station or for diagnostic purposes.

Receive Heartbeat

The default configuration for “Receive Heartbeat” is 300 sec. If no nvi update is received during this time, the actuators will go to their configured safety positions. Start-up Behavior At start-up, i.e., power-up or reset, all nvi's will be initialized with INVALID, and after 1 minute, the actuators will go to their configured safety position One instance of the LONMARK open-loop sensor object has been assigned per input of the XFL823 Binary Input Module. Each digital input object has its own configuration properties, except for heartbeat configuration, which will be shared among all objects.
