Siemens 6ES5417-7AA21 Digital Output Module

Siemens 6ES5417-7AA21 Digital Output Module

Product Details Introduction

Siemens 6ES5417-7AA21 is a digital output module in the Siemens S5 series, designed specifically for industrial automation and control applications. The following is the detailed information of the module:

main features

Product model: 6ES5417-7AA21

Series: Siemens S5

Type: Digital Output Module

major function

Digital output: This module is capable of converting logic signals from the controller into digital output signals to control various actuators such as relays, valves, and motors.

Output channel: It has multiple independent output channels, with a specific quantity of 16, which can drive various devices as needed.

technical parameter

Output type:

The rated current of each output channel is usually between 0.5A and 2A (please refer to the technical manual for specific values).

Support switch voltage range: capable of processing 24V DC signals.

Connection method: Adopting a plug-in design for easy installation and maintenance.

Response time: Fast output response time, suitable for applications that require real-time control.

application area

Industrial automation: widely used in manufacturing, processing industry, mechanical control and other fields.

Process control: can be used in industries such as chemical, pharmaceutical, and food processing, responsible for controlling various equipment on the production line.

Equipment control: used to control the operation of equipment such as motor start/stop, valve opening/closing, etc.

Installation and compatibility

Installation method: The module is designed as a plug-in type, suitable for installation in S5 series racks for easy replacement and maintenance.

Compatibility: Compatible with other modules and components of Siemens S5 series, supporting flexible system integration.

advantage

High reliability: Industrial grade design ensures stable operation in harsh environments.

Flexibility: The multi output design enables it to adapt to multiple control strategies and meet different industrial needs.

Easy maintenance: The plug-in design simplifies the maintenance process and reduces downtime.

matters needing attention

Electrical connections: When installing and wiring, please ensure that all connections are correct to avoid equipment damage or functional failure.

Load requirement: Please ensure that the connected load is within the rated output range of the module to avoid damaging the module.

Product image
