Siemens 6EP1332-1SH71 power module

Siemens 6EP1332-1SH71 power module

Product Details Introduction

Siemens 6EP1332-1SH71 is the SITOP PSU100C power module in the SIMATIC S7 series, specifically designed to provide stable and reliable DC power for industrial automation systems. This power module has a compact design, suitable for use in control cabinets with limited space, and provides efficient power conversion.

Main specifications and features:

Model: 6EP1332-1SH71

Series: SITOP PSU100C

Input voltage:

85V to 264V AC (wide range AC input)

120V to 350V DC (DC input)

Output voltage: 24V DC

Output current: 2.5A (i.e. maximum power of 60W)

Efficiency: over 88%, energy-saving and environmentally friendly

Size: 32.5mm wide, compact design saves control cabinet space

Working temperature range: -20 ° C to+70 ° C

Protection function: equipped with short circuit, overload, and overvoltage protection to ensure reliability during operation under harsh conditions

Installation method: DIN rail installation, easy to integrate into industrial control systems

Certification standards: Compliant with multiple international standards (such as CE, UL certification), suitable for global market applications

Functional features:

High efficiency conversion: With over 88% energy efficiency, it reduces energy loss, saves energy, and is suitable for industrial equipment that operates for long periods of time.

Compact design: With a width of only 32.5mm, it is suitable for installing control cabinets in narrow spaces.

High reliability: Built in short-circuit protection, overload protection, and overvoltage protection can protect power modules and load devices in case of accidents.

Wide input voltage range: Supports a wide voltage input range, allowing for stable output voltage even in unstable voltage environments.

Adaptable to harsh environments: capable of working in temperatures as low as -20 ° C and as high as 70 ° C, suitable for various harsh industrial environments.

Application scenarios:

Industrial automation: Provide 24V DC stable power supply for PLC, HMI, sensors, actuators and other equipment.

Control cabinet: used for power supply in control cabinets with limited space.

Industrial equipment: It can provide stable power support for various industrial equipment and automation systems.

Mechanical manufacturing: applied to manufacturing equipment and robot systems that require stable DC power supply.

Product image
