Siemens 6EP1334-1AL11 Programmable Power Module

Siemens 6EP1334-1AL11 Programmable Power Module

Product Details Introduction

Siemens 6EP1334-1AL11 is a programmable power module in the SITOP PSU8600 series, designed for high demand industrial automation systems, particularly suitable for complex control and monitoring applications. This module integrates multiple outputs, flexible programming functions, and intelligent monitoring and management, and is one of the key power management components in Industry 4.0 solutions.

Main specifications and features:

Model: 6EP1334-1AL11

Series: SITOP PSU8600

Input voltage:

85V to 264V AC (wide range AC input)

110V to 300V DC (DC input)

Output voltage:

Default 24V DC, adjustable through software (range 22V to 28V DC)

Output current: 20A (maximum power 480W)

Efficiency: up to 94%, reducing energy consumption and minimizing heat generation

Size: Compact design, suitable for control cabinet installation

Output channels: 4 independent adjustable output channels, each channel can be independently programmed

Communication interface: Supports Profinet or Ethernet interfaces, can be integrated into industrial networks

Status monitoring: Built in intelligent monitoring function, which can monitor power status, output voltage, current and other parameters in real time through communication interface

Protection function:

Short circuit protection

overload protection

Overvoltage protection

Temperature protection

Installation method: DIN rail installation, industrial standard design

Certification: Through various international certifications such as CE, UL, CSA, etc., it meets the industrial application requirements of the global market

Functional features:

Multi output programming: 4 independent programmable outputs, each voltage and current can be adjusted through software to flexibly respond to different device and load requirements.

Efficient Energy Management: This module can operate at up to 94% efficiency, effectively reducing power consumption and making it suitable for energy-saving industrial automation applications.

Integrated communication capability: Supports Profinet and Ethernet protocols, enabling remote monitoring and control of power supply operation status through industrial networks, achieving intelligent power management under Industry 4.0.

Intelligent monitoring and alarm: Real time monitoring of various operating parameters of the power supply (such as voltage, current, temperature, etc.), and the ability to trigger alarms in case of abnormalities, ensuring the safe operation of the system.

Flexibility and Scalability: Modular design allows for the extension and customization of other SITOP modules to meet different system requirements, with strong scalability.

Strong adaptability to industrial environments: suitable for operation in harsh industrial environments, with a wide temperature operating range and electromagnetic interference resistance.

Application scenarios:

Industrial automation: providing flexible and reliable power solutions for industrial robots, PLCs, sensors, and actuators.

Process control system: In complex process control systems, real-time monitoring and adjustment of power supply can ensure efficient operation of the system.

Intelligent Manufacturing: Suitable for Industry 4.0 environments, providing programmable and remotely managed power solutions, supporting energy management for smart factories.

Data Center and Communication Equipment: Supports critical systems that require stable and intelligent power management, such as data centers and communication equipment.

Building automation and energy management: used for large-scale building systems and energy management systems, providing efficient power distribution and monitoring.

Product image
