Siemens 6EP1334-1SH01 power module

Siemens 6EP1334-1SH01 power module

Product Details Introduction

Siemens 6EP1334-1SH01 is a power module in the SITOP PSU200M series, designed to provide efficient and stable DC power for industrial automation and control systems. This module is characterized by its wide input voltage range and powerful protection function, making it suitable for industrial environments that require high reliability.

Main specifications and features:

Model: 6EP1334-1SH01

Series: SITOP PSU200M

Input voltage:

120V to 230V AC (wide range AC input)

110V to 300V DC (DC input)

Output voltage: 24V DC

Output current: 10A (maximum power 240W)

Efficiency: 94% (under high load conditions), reducing power consumption and minimizing heat generation

Size: Compact design with a width of approximately 70mm, convenient for installation inside the control cabinet

Working temperature range: -25 ° C to+70 ° C, suitable for harsh industrial environments

Protective function:

Short circuit protection

overload protection

Overvoltage protection

Temperature protection

Installation method: DIN rail installation, in compliance with industry standards, easy to integrate into existing control systems

Certification: Passed international certifications such as CE, UL, CSA, etc., suitable for industrial applications worldwide

Functional features:

High efficiency design: 6EP1334-1SH01 has an efficiency of up to 94%, which means it can reduce energy loss under high loads and thus lower system operating costs.

Wide input voltage range: This power module supports a wide input voltage range, ensuring stable 24V DC output voltage even in unstable power grid environments.

Powerful protection function: Built in short circuit, overload, overvoltage, and overtemperature protection, ensuring that the power supply and connected devices can avoid damage from electrical faults during operation.

Compact design: Only 70mm in width is suitable for control cabinets with limited space, saving valuable installation space.

Stable Voltage Output: Provides a stable 24V DC output that can maintain a constant voltage even in the event of input voltage fluctuations, providing reliable power support for the stable operation of the control system.

Low power consumption and high efficiency: This module not only maintains efficient operation under heavy loads, but also achieves low power consumption even under light loads, making it suitable for industrial equipment that operates continuously for long periods of time.

Application scenarios:

Industrial automation: providing stable power supply to PLC (Programmable Logic Controller), sensors, actuators and other equipment.

Mechanical manufacturing: providing reliable power supply for manufacturing equipment, robot systems, etc.

Process control system: suitable for power supply in automated process control, ensuring smooth operation of the system.

Energy and Power Management: Applied to energy management systems or power facilities to ensure continuous operation of equipment.

Building automation: providing power support for building automation equipment, such as security systems, control systems, etc.

Product image
