Siemens 6ES712-1BA01-0XB0 Relay Module
Product Details Introduction
Siemens 6ES712-1BA01-0XB0 is a CPU 222 AC/DC/relay module in the SIMATIC S7-200 series. This module is a small programmable logic controller (PLC) suitable for various small and medium-sized automation applications. It integrates digital input and relay output functions, making it particularly suitable for directly driving external devices such as motors, lights, heaters, etc.
Main technical specifications:
Type: SIMATIC S7-200 CPU 222 AC/DC/Relay
Input/output points:
8 digit inputs
6 relay outputs: Relay outputs can directly drive inductive and resistive loads.
Power supply voltage:
AC input voltage: 85-264 V AC
DC power supply range: 24 V DC
Storage capacity:
Program memory: 4 KB
Data storage: 4 KB
Communication interface: RS-485 interface, supporting PPI (point-to-point communication) protocol. Can communicate with other PLC devices, human-machine interface (HMI), or upper computer.
Loop time: The execution time of basic instructions is 0.37 µ s/instruction, ensuring fast response time.
Working temperature: 0 ° C to 55 ° C, suitable for industrial environments.
Size: Compact design, easy to integrate into control cabinets.
Functional features:
Relay output: This module is equipped with 6 relay outputs, which can directly control external devices such as motor start-up, switches, etc., without the need for additional intermediate relays.
Multi functional: Provides counters, timers, and pulse width modulation (PWM) outputs, suitable for complex control tasks.
Scalability: Supports adding additional I/O points through expansion modules to flexibly adapt to different automation needs.
Programming support: Use STEP 7-Micro/WIN software for programming, supporting ladder diagrams (LAD) and instruction lists (IL), simplifying program development.
Communication capability: Communication with other devices is achieved through RS-485 interface, which facilitates the construction of control networks for multiple devices.
Product image
