Siemens 6ES712-1CA00-0XB0 Compact Unit
Product Details Introduction
Siemens 6ES712-1CA00-0XB0 is a compact unit of CPU 224XP AC/DC/relay in the SIMATIC S7-200 series. This module belongs to the small programmable logic controller (PLC) series, with strong input and output expansion capabilities and rich functional features, designed specifically for small and medium-sized automation control tasks.
Main technical specifications:
Type: SIMATIC S7-200 CPU 224XP AC/DC/Relay
Input/output points:
14 digit inputs
10 digital outputs
2 analog inputs
1 analog output
Power supply voltage: AC input, 85-264 V AC
Storage capacity:
Program memory: 16 KB
Data storage: 10 KB
Communication interface: Integrated with 2 RS-485 interfaces, supporting PPI (point-to-point communication), MPI (multi-point communication), and free port mode.
Loop time: The basic instruction execution time is 0.22 microseconds per instruction, supporting high-speed processing.
Working temperature: 0 ° C to 55 ° C, suitable for use in various industrial environments.
Size: Compact design, easy to install in control cabinets with limited space.
Functional features:
Rich input-output configuration: This module has 14 digital inputs, 10 digital outputs, and an additional 2 analog inputs and 1 analog output, capable of processing both digital and analog signals, suitable for various industrial application scenarios.
Relay output: Relay output directly controls external loads such as motors, valves, and other devices without the need for additional relay modules, simplifying system design.
Dual RS-485 communication interface: supports two independent RS-485 communications, can be used for data communication with other PLCs, HMIs, or other peripheral devices, and supports multiple communication protocols (PPI, MPI, Freeport).
Extended support: By extending the module, additional input and output points can be added to adapt to the constantly growing project requirements.
Programming and functional support: Supports programming using STEP 7-Micro/WIN software, supports multiple programming languages such as ladder diagrams and instruction lists, simplifies the development and debugging process. Built in multiple advanced functions, such as high-speed counter, pulse width modulation (PWM), etc.
High speed performance: Fast execution time, able to quickly respond to complex automation control tasks, suitable for application scenarios with high requirements for response speed.
Product image
