Siemens 6ESC214-1AC00-0XB0 central processing unit

Siemens 6ESC214-1AC00-0XB0 central processing unit

Product Details Introduction

Siemens 6ES7214-1AC00-0XB0 is the CPU 226 AC/DC/relay central processing unit (CPU) in the SIMATIC S7-200 series. This CPU is a high-end module in the S7-200 series, with large input and output capacity and powerful processing capabilities, suitable for complex medium-sized automation control systems.

Main technical specifications:

Type: SIMATIC S7-200 CPU 226 AC/DC/Relay

Input/output points:

24 digit input

16 relay outputs: can directly control external devices such as motors, valves, heaters, etc.

Power supply voltage:

AC input voltage: 85-264 V AC

DC power output: 24 V DC, used for external device power supply.

Storage capacity:

Program memory: 24 KB

Data storage: 10 KB

Communication interface: Integrated with 2 RS-485 interfaces, supporting PPI, MPI, and Freeport modes.

Loop time: The basic instruction execution time is 0.22 microseconds per instruction, supporting fast processing.

Working temperature: 0 ° C to 55 ° C, suitable for daily operation in industrial environments.

Size: Compact design, suitable for the space requirements of control cabinets.

Functional features:

Multi input/output configuration: Provides 24 digital inputs and 16 relay outputs, capable of meeting the large-scale requirements of complex control systems.

Relay output: It can directly control the load and is suitable for various industrial equipment, without the need for additional relays, greatly simplifying wiring and installation.

Dual RS-485 communication interface: supports two independent communication channels, suitable for data exchange with multiple devices, PLCs, or HMIs. Supports PPI, MPI, and free port modes, increasing communication flexibility.

Powerful processing capability: 24 KB of program memory allows users to create complex automation programs that are adaptable to various industrial applications.

Flexible scalability: Supports increasing the number of input and output points through expansion modules, as well as expanding other functions (such as analog modules) to meet the constantly growing project requirements.

Advanced feature support: This CPU supports high-speed counting, pulse width modulation (PWM) output, analog processing, and other functions, and can be used for complex industrial control tasks.

Programming and Debugging: STEP 7-Micro/WIN software can be used for programming, supporting programming languages such as Ladder Diagram (LAD) and Instruction List (IL) to simplify the development and debugging process.

Product image
