Siemens 6ES7214-1AC01-0XB0 Controller

Siemens 6ES7214-1AC01-0XB0 Controller

Product Details Introduction

Siemens 6ES7214-1AC01-0XB0 is a CPU 226 AC/DC/relay controller in the SIMATIC S7-200 series. This module is a high-performance product of the series, suitable for complex medium-sized automation tasks, capable of managing multiple input/output devices and executing efficient logic control.

Main technical specifications:

Type: SIMATIC S7-200 CPU 226 AC/DC/Relay

Input/output points:

24 digit input

16 digital relay outputs

Power supply voltage:

AC input: 85-264 V AC

Output: 24 V DC (used to provide power for external devices)

Storage capacity:

Program memory: 24 KB

Data storage: 10 KB

Communication interface:

2 RS-485 interfaces: Supports PPI (point-to-point communication), MPI (multi-point communication), and Freeport mode.

Loop time: The basic instruction execution time is 0.22 microseconds per instruction, suitable for fast response and processing of complex tasks.

Working temperature: 0 ° C to 55 ° C, suitable for various industrial environments.

Size: Compact design, suitable for use in control cabinets with limited space.

Functional features:

Input/output configuration: 24 digital inputs and 16 relay outputs, capable of processing complex digital signals and directly controlling external devices such as motors and valves.

High performance processing: The CPU 226 has 24 KB of program memory and 10 KB of data memory, which can store and execute complex automation control programs.

Dual RS-485 interface: Supports two independent RS-485 communication ports, facilitating communication with other PLCs, HMIs, or peripheral devices, suitable for multi device integration.

Flexible Expansion: Supports increasing input and output points through expansion modules, and can add analog modules, communication modules, etc. to meet the needs of larger projects.

Relay output: 16 relay outputs support direct control of external devices, reducing the need for additional relay modules and simplifying system design.

High speed function support: Supports advanced functions such as high-speed counters and pulse width modulation (PWM) outputs, suitable for application scenarios that require high-precision control.

Programming and Debugging: Supports STEP 7-Micro/WIN programming software, providing multiple programming languages such as ladder diagrams and instruction lists to simplify debugging and maintenance.

Product image
