Siemens 6ES7214-1AD21-0XB0 CPU module

Siemens 6ES7214-1AD21-0XB0 CPU module

Product Details Introduction

Siemens 6ES7214-1AD21-0XB0 is a CPU 224XP AC/DC/relay module in the SIMATIC S7-200 series. This module belongs to the mid-range CPU and is suitable for small and medium-sized automation projects. It provides strong input and output capabilities and flexible scalability, and is widely used in industrial automation control systems.

Main technical specifications:

Type: SIMATIC S7-200 CPU 224XP AC/DC/Relay

Input/output points:

14 digit inputs

10 digital outputs (relay outputs)

2 analog inputs

1 analog output

Power supply voltage:

AC input: 85-264 V AC

Output: 24 V DC, used to power external devices.

Storage capacity:

Program memory: 16 KB

Data storage: 10 KB

Communication interface:

1 RS-485 communication interface: supports PPI (point-to-point communication) and Freeport mode.

Loop time: The basic instruction execution time is 0.22 microseconds per instruction, supporting fast response control applications.

Scalability: Supports up to 7 expansion modules to increase input/output points or functionality.

Working temperature: 0 ° C to 55 ° C, suitable for industrial environments.

Functional features:

Multi input/output configuration: This module provides 14 digital inputs, 10 relay outputs, 2 analog inputs, and 1 analog output, suitable for diverse control needs and capable of directly processing digital and analog signals.

Integrated Analog Input/Output: The built-in analog input/output allows it to directly process sensor signals or adjust analog devices without the need for additional analog modules, saving costs and space.

Relay output: 10 relay outputs can directly control external loads such as motors and valves without the need for external relay modules.

Flexible expansion capability: Supports up to 7 expansion modules, able to increase input and output points or add special functional modules (such as analog modules, communication modules, etc.) according to needs.

Communication interface: Built in RS-485 interface, supporting PPI and free port modes, can be used for communication with other PLCs, HMIs, or external devices.

High speed counting and pulse output: Supports high-speed counter and pulse output functions, suitable for applications that require precise timing or motion control.

Product image
