Product Details Introduction

Siemens 6ES7214-1AD22-0XB0 is a CPU 224XP DC/DC/relay module in the SIMATIC S7-200 series. This controller is designed for medium-sized automation tasks, with strong input-output capabilities and flexible functional scalability. It integrates digital and analog input-output functions and is equipped with relay control, making it suitable for various industrial control applications.

Main technical specifications:

Type: SIMATIC S7-200 CPU 224XP DC/DC/Relay

Input/output points:

14 digit inputs

10 digital outputs (relay outputs)

2 analog inputs

1 analog output

Power supply voltage: DC power supply, with a voltage range of 20.4 V to 28.8 V DC.

Storage capacity:

Program memory: 16 KB

Data storage: 10 KB

Communication interface:

1 RS-485 interface: supports PPI (point-to-point communication), MPI (multi-point communication), and Freeport mode.

Loop time: The basic instruction execution time is 0.22 microseconds per instruction, supporting fast response control.

Scalability: Supports up to 7 expansion modules to increase input/output points or add special function modules.

Working temperature: 0 ° C to 55 ° C, suitable for operation in industrial environments.

Functional features:

Integrated analog processing: This module integrates 2 analog inputs and 1 analog output, suitable for directly processing sensor signals or adjusting analog devices, reducing the need for external analog modules.

Relay output: 10 relay outputs allow direct control of external load devices such as motors, valves, etc., making the system more compact and efficient.

High speed processing: It has fast basic instruction execution time, can quickly respond to the needs of industrial control tasks, and supports advanced functions such as high-speed counters and pulse output.

Flexible scalability: Supports up to 7 expansion modules, allowing for the addition of more I/O points or special features (such as analog modules, communication modules, etc.) according to project requirements.

Communication interface: Built in RS-485 interface, supporting PPI, MPI, and free port communication methods, capable of flexible networking communication with other devices.

Product image
