Siemens 6ES7214-1AD23-0XB0 Compact Unit Module

Siemens 6ES7214-1AD23-0XB0 Compact Unit Module

Product Details Introduction

Siemens 6ES7214-1AD23-0XB0 is a compact unit module with CPU 224XP DC/DC in the SIMATIC S7-200 series, suitable for small and medium-sized automation control projects. This module integrates multiple input and output functions, provides high-performance control capabilities, and can be flexibly expanded, widely used in various industrial automation tasks.

Main technical specifications:

Type: SIMATIC S7-200 CPU 224XP DC/DC/DC

Input/output points:

14 digit inputs

10 digital outputs (transistor output)

2 analog inputs

1 analog output

Power supply voltage: DC power supply, with a voltage range of 20.4 V to 28.8 V DC.

Storage capacity:

Program memory: 16 KB

Data storage: 10 KB

Communication interface:

1 RS-485 interface: supports PPI (point-to-point communication), MPI (multi-point communication), and Freeport mode.

Loop time: The basic instruction execution time is 0.22 microseconds per instruction, supporting fast response control tasks.

Scalability: Supports up to 7 expansion modules, which can add more input/output or functional modules.

Working temperature: Suitable for industrial environments ranging from 0 ° C to 55 ° C.

Functional features:

Multi input/output configuration: This module provides 14 digital inputs, 10 digital outputs (transistor outputs), 2 analog inputs, and 1 analog output, capable of processing various digital and analog signals, suitable for complex control tasks.

Integrated analog input/output: The built-in 2 analog inputs and 1 analog output can directly process analog signals, such as sensor inputs and actuator control, without the need for external analog modules.

High speed processing capability: The basic instruction execution speed is 0.22 microseconds per instruction, supporting high-speed counting and pulse output, suitable for control tasks with high real-time requirements.

Flexible scalability: By adding up to 7 expansion modules, more I/O points or functional modules can be added, such as analog modules, communication modules, etc., to meet the expansion needs of different projects.

Communication interface: The built-in RS-485 interface supports PPI and MPI communication methods, enabling networked communication with other PLCs, HMIs, or external devices.
