Siemens 6ESC214-1BC00-0XB0 Central Processing Unit

Siemens 6ESC214-1BC00-0XB0 Central Processing Unit

Product Details Introduction

Siemens 6ES7214-1BC00-0XB0 is the CPU 226 AC/DC/Relay Central Processing Unit (CPU) in the SIMATIC S7-200 series. This module has powerful processing capabilities and flexible expansion options, making it suitable for medium to large-scale automation tasks, especially in applications that require high I/O points and complex control functions.

Main technical specifications:

Type: SIMATIC S7-200 CPU 226 AC/DC/Relay

Input/output points:

24 digit input

16 digital outputs (relay outputs)

Power supply voltage: AC power supply, with a voltage range of 85V to 264V AC.

Storage capacity:

Program memory: 24 KB

Data storage: 10 KB

Communication interface:

2 RS-485 interfaces: Supports PPI (point-to-point communication), MPI (multi-point communication), and Freeport mode.

Loop time: The basic instruction execution time is 0.22 microseconds per instruction, supporting fast response control tasks.

Scalability: Supports up to 7 expansion modules, which can increase the number of input/output points or other functional modules.

Working temperature: Suitable for industrial environments ranging from 0 ° C to 55 ° C.

Functional features:

Rich input-output configuration: This module provides 24 digital inputs and 16 relay outputs, which can meet the needs of large-scale digital signal processing.

Relay output: Relay output provides the module with the ability to directly control external devices, such as motors, valves, and other industrial equipment, without the need for an external output module.

Large storage capacity: With 24 KB of program memory and 10 KB of data memory, it can handle complex automation control tasks.

Dual communication interface: integrates 2 RS-485 communication interfaces, supports multiple communication protocols, and facilitates network communication with other PLCs, HMIs, and external devices.

Flexible Scalability: With up to 7 expansion modules, it is possible to increase the number of I/O points or add functional modules (such as analog modules, communication modules, etc.) to meet complex automation requirements.

Application areas:

The Siemens 6ESC214-1BC00-0XB0 central processing unit module is suitable for medium to large-scale automation tasks, and its main application scenarios include:

Industrial automation: used for complex control tasks such as production lines, packaging equipment, assembly machinery, etc.

Process control: Used for complex process control in industries such as chemical, pharmaceutical, and food processing.

Energy management: a control system used for energy distribution, monitoring, and optimized management.

Building Automation: Suitable for HVAC, lighting, and security control in building automation.

Product image
