Siemens 6ES7214-1BC01-0XB0 Input/Output Module

Siemens 6ES7214-1BC01-0XB0 Input/Output Module

Product Details Introduction

Siemens 6ES7214-1BC01-0XB0 is a CPU 226 AC/DC/relay input/output module in the SIMATIC S7-200 series, which integrates multiple input/output functions and is particularly suitable for automation tasks that require a large number of I/O points. It provides rich digital inputs and relay outputs, suitable for medium to large automation control systems.

Main technical specifications:

Type: SIMATIC S7-200 CPU 226 AC/DC/Relay

Input/output points:

24 digit input

16 digital outputs (relay outputs)

Power supply voltage: AC power supply, with a voltage range of 85V to 264V AC.

Storage capacity:

Program memory: 24 KB

Data storage: 10 KB

Communication interface:

2 RS-485 interfaces: Supports PPI, MPI, and Freeport modes for communication with other devices.

Loop time: The basic instruction execution time is 0.22 microseconds per instruction.

Scalability: Supports up to 7 expansion modules, which can increase the number of I/O points or specific functional modules.

Working temperature: 0 ° C to 55 ° C.

Functional features:

Rich input/output configuration: Provides 24 digital inputs and 16 relay outputs, capable of handling a large number of signal inputs and device control outputs.

Relay output: The integrated relay output is suitable for controlling scenarios that require switching high-power electrical equipment, such as motors, lights, or solenoid valves.

Large capacity storage: 24 KB program storage and 10 KB data storage, supporting complex program logic processing.

Dual RS-485 communication interface: supports multiple communication protocols, can communicate with other PLCs, HMIs or peripheral devices, and flexibly build distributed control systems.

Strong scalability: It can connect up to 7 expansion modules and can flexibly increase the number of input and output points or functional modules according to needs.

Product image
