Siemens 6ES7214-1BC10-0XB0 Logic Controller

Siemens 6ES7214-1BC10-0XB0 Logic Controller

Product Details Introduction

Siemens 6ESP2714-1BC10-0XB0 is a CPU 226 DC/DC logic controller in the SIMATIC S7-200 series. This logic controller is mainly used for complex automation control tasks, with large input and output capacity and flexible communication and expansion capabilities. It is an ideal choice for medium-sized to large-scale automation systems, suitable for use in industries such as energy management and building automation.

Main technical specifications:

Type: SIMATIC S7-200 CPU 226 DC/DC/DC

Input/output points:

24 digit input

16 digital outputs (transistor outputs)

Power supply voltage: DC power supply, with a voltage range of 20.4 V to 28.8 V DC.

Storage capacity:

Program memory: 24 KB

Data storage: 10 KB

Communication interface:

2 RS-485 interfaces: Supports PPI (point-to-point communication), MPI (multi-point communication), and Freeport mode.

Output type: transistor output, supporting high-speed control and fast switching.

Loop time: The basic instruction execution time is 0.22 microseconds per instruction, suitable for high-speed real-time control tasks.

Scalability: Supports up to 7 expansion modules, increasing input/output points or special function modules.

Working temperature: Suitable for industrial environments ranging from 0 ° C to 55 ° C.

Functional features:

Rich input and output: 24 digital inputs and 16 transistor outputs, capable of handling a large number of digital signal inputs and device control outputs.

Transistor output: The transistor output supports high-speed response and is suitable for devices that require fast switching and control, such as servo motors, robots, and other automation equipment.

Powerful storage capacity: 24 KB of program memory and 10 KB of data memory, sufficient to handle complex automation control logic.

Dual RS-485 communication interface: supports multiple communication protocols such as PPI, MPI, and Freeport mode, and can communicate with multiple peripheral devices, PLCs, HMIs, and sensors.

Flexible Expansion: Supports up to 7 expansion modules, allowing for flexible addition of more input/output points or functional modules (such as analog modules, communication modules, etc.) to meet complex automation requirements.

Product image
